SCS 8 – 8 way splitter TRIAX coaxial splitter ideal for SAT-IF and MATV distribution networks. Features Frequency range 5-2400 MHz DC pass via diodes from all outputs High shielding against ingress noise like radiated by LTE mobile High quality die-cast housing tin (Sn) coated with solder shield bottom plate Grounding clamp terminals Formerly triax-349808 Specifications ORDER INFORMATION EAN Number 5702663498280 FREQUENCY RANGE Frequency range 5…2400 MHz OPERATIONAL Application SAT-IF, MATV 2.4Ghz +DC(out->in) Screening Efficiency EN50083-2 (Class A) DC Passthrough Yes (max. 0.5A/24V) Certification EN 50581:2012 (RoHS II) Environment Indoor Temperature – operating -30**+60 **C LOSS Insertion loss (in-out) 5-40…
