Distributor with 3 TDT Outputs with F Connector 8 dB from Televes
Televes 3-output DTT splitter with F connector
The distributor is a 3**3**outputs**of small size with **F**female connection that allows to work in the frequency range from 5 to 1220 MHz.
This distributor has a**good performance**at high frequencies, with low attenuations and high shielding efficiencies.**It improves pass-through losses**and provides a**good shielding.
It includes the grounding screw. Great mounting flexibility as it can be installed screwed to the wall, on rack plates or on DIN rail (in the latter case, with adapter 519901).**
Its**connection is very simple since the angle of inclination of 10** that it has, facilitates the screwed of the connectors F. In addition, it allows the passage of the wiring by its rear part.
This range of distributors can be chained to each other, through the grounding screw itself, so that we will only use a single grounding wire.**
Technical Specifications of the Televes 3 Output F Connector TDT Distributor
Frequency range MHz 5 … 1220
Number of outputs ? 3
Passage losses dB
8
Rejection between departures dB
> 20
Connectors ? “F” female
