Housing Internal Amplifier 3 outputs
Housing Amplifier 3 outputs (2s+TV) + c. passive return 553001
This device has 1 input and 3 outputs, with F connection. It is used when we want to expand the home television network.
You will be able to amplify the terrestrial and satellite band with passive return path. The TV signal has a higher gain to be able to connect to the TV directly (without installing an outlet). The gain can be controlled manually.
Compact in size and lightweight, it is presented in white. Its integrated switching power supply produces a 40% reduction in consumption compared to a common amplifier.
The amplifier can be installed screwed to the wall.
Technical Specifications of the Home Amplifier 3 outputs (2+TV) + c. passive return 553001
?
Output 3 (2+TV) (F)
Frequency range MHz 5…65 (RET) 88…862 950-2150
Gain dB -9
(-16 @ TV) 19
(11 @ TV) 21
(13 @ TV)
Regulation margin
profit – 12 –
Equalizer – – –
Output level DIN 45004B Vout dB?V – 111 114
Noise figure dB – 4 3
Mains voltage/frequency V~/Hz 110…230/ 50…60
Total AC consumption W/mA < 3,2 / 57
Pass current DC S/E mA 300 m?x
Protection index IP 20
Operating temperature range ?C -5 ... +45
?
