Ikusi SRT-005 Support 1 strip of 5 pairs for RPT-005
KSh124.00
Frame stainless steel strip 5 pr.
TECHNICAL SPECIFICATIONS
INSTALLATION MANUAL
Related products
-
Add to cartIKUSI ARP-012. 19″rack cabinets with glass front door
Features
6 pcs wall racks for small installations.
One-piece chassis that gives it great robustness.
The interior guides are adjustable in depth and the sides are accessible, thus providing great versatility and functionality.
Technical specifications
MODEL ARP-006 ARP-012
Ref. 8228 8229
Height units 6U 12U
Material SPCC Cold Rolled Steel
Colour Black RAL9005
Thickness 2 mm
Static charge 60 kg
Front door Kind Glass door
Lock Spring lock
Rear panel Kind Yes
Lock Not
Removable side panel Yes (with key)
Upper cable entry Yes
Bottom cable entry Yes
Wall bracket Yes
Vertical racks Quantity 4
U marking Printed
Fixing screws U twenty
IP twenty
Measures Width 600 mm 600 mm
Deep 400 mm 600 mm
High 6U) 370 mm (12U) 635 mmMANUAL / DATASHEET
-
Read moreAlcad DI-803 – Serie 906: If splitter 8 out with dc path.
8-way splitter for terrestrial and satellite TV, covering all frequencies from 5MHz to 2,400MHz. It distributes all the input signal in equal parts among the 8 outputs. It has a feed path through any of its 8 outputs to the input. The response of the outputs is flat. Also available in 2-, 3-, 4- or 6-way models.
Applications
Individual and collective installations of terrestrial and satellite TV with a star-shaped distribution. They permit power to be fed from a preamplifier or LNB through any of the outputs. In installations with multiswitches, a control voltage can be sent through their outputs.
Characteristics
Protection diodes in all the outputs. Shielded zamak chassis and metal plate. Zamak F-type connectors which form part of splitter chassis.
Downloads
Technical specification
Technical specification
Manuals
DI-803 Manual pdf 923.93 KB
Catalogues
CATALOGUE_ALCAD_EN_MULTIMEDIA_TV pdf 5.42 MB
Certificates
CE Declaration – 906-DI_20210426 pdf 70.31 KB
Technical specifications
-
Read moreAlcad BS-102 – Serie 907: If terminal outlet, 2 db, 3 connectors.
Outlets for terrestrial and satellite TV with three male IEC connectors, an IEC female connector and an F-type female connector. They cover frequencies up to 2,300MHz. They allow a feed path via the female F-type connector to the input.
Applications
Outlets for terrestrial and satellite TV with three male IEC connectors, an IEC female connector and an F-type female connector. They cover frequencies up to 2,300MHz. They allow a feed path via the female F-type connector to the input.
Characteristics
Shielded zamak and metal plate chassis. Connection of the coaxial cable by means of screw terminal. Includes TV/R/SAT frontplate, surface box and screws for fixing to a wall.
Downloads
Technical specification
Technical specification
Catalogues
CATALOGUE_ALCAD_EN_MULTIMEDIA_TV pdf 5.42 MB
Technical specifications
-
-
Read moreAlcad PT-320 – Serie 907: If user acces point, if splitter 3 out.
User access point for terrestrial and satellite TV. It has two inputs and three outputs. One of the inputs remains connected to the outputs while the other input is permanently connected to a 75 ohm load. Designed for the 5-2,400 MHz frequency range. Also available in 2-, 4-, 5-, 6- and 8-output models.
Applications
Designed for TV installations with two coaxial cables in which distribution to the houses is performed with a single coaxial cable. The signal which is distributed to the house is selected by changing the connections of the coaxial cables at the user access point.
Characteristics
Voltage blockage in the output connectors. No return path. Shielded zamak and metal plate chassis. F type connectors in machined zamak which form part of the chassis. Reduced dimensions.
Downloads
Technical specification
Technical specification
