Ikusi SZB-168: Digital Radio Amplifier Gain 53dB, Output…
KSh20,048.00
Digital Radio Amplifier Gain 53dB, Output level 2x113dB**V
Additional info
Data Sheet
Installation Manual
Related products
-
Add to cartStock available in channels C22, C27, C28, C32, C35, C38, C39, C42 and C45.
Single channel UHF amplifier, 52dB Gain, Output Level 2x121dB**V
Main features
TV single-channel and multichannel amplifiers, the last ones especially created for amplification of combined analog and digital channels. Z input de-multiplexing and Z output multiplexing. Adjacent channel operation allowed in UHF band.
It is advisable to place the amplifiers on the base-plate following an increasing order of number of channel (frequency).
The RF output of the headend will be taken from the last one of the modules ordered in this way.
Additional infoData Sheet
Installation Manual
-
Add to cartBII (FM) amplifier with 30dB gain and 2x113dB**V output level
Additional info
Data Sheet
Installation Manual
-
Add to cartIKUSI BAS-915. Base plate with power connecting bar. Capacity: 1 power supply+4 RF modules SZB; or 5 RF modules
Features
Support base with power bar. Capacity: 1 feeder + 4 RF modules; or 5 RF modules. -
Amplifier FM/DAB TAS 240 40dB Triax
KSh11,268.00Add to cartThis module allows the FM and DAB signals to be amplified separately. The gain can be regulated from 0 – 20 dB in each frequency band.
Specifications
**Model ** TAS 240**
Code ** **324848
Frequency band MHzFM: 87.5 – 108**
DAB: 195 – 223
Gain dB 40**
Attenuation dB 0 – 20**
Output level dB**V110
(DIN B – 35dB)**
Feeding
VCD 12 to 24**
Consumption mA 150**
Connectors ** F female
Impedance ** 75
Dimensions** mm. 225 x 65 x 30
Example of chassis mounting -
Ikusi PLZ-017 Bridge SZB F-F
KSh506.00Add to cartIKUSI PLZ-017. Bridge SZB F-F
Features
Hose-Bridge with F-F connector**
MANUAL/DATASHEET
