Indoor 5G filter with cut on channel 48 with Televes DC
Indoor LTE700 filter for the 5G channel 48
Filter 5G low pass 403201 of Televes to install indoors. This high rejection filter has the cutoff frequency on channel 48 and eliminates all interference with the 5G band by applying a 20dB signal attenuation from channel 49.
This LTE2 filter has an ultra-small size and very low through loss, it has an F-type male connector at the output and a plug-in format at the input, compatible with any equipment with an F connection.
Indoor 5G filter with cutoff frequency on channel 48 (694 MHz), compact and lightweight.
What technical specifications does the Televes 5G 403201 Filter have?
Frequency margin MHz 47 – 774 791 – 862
Attenuation dB 1 > 20
Inputs/Outputs n? 1 / 1
Max current through inputs mA 300
Temperature operat. limits ?C -5 … +45
Protection Level IP 20
