Description

INNOVA BOSS omnidirectional indoor antenna with LTE filter adapted to 5G that will arrive in Spain by next year 2020.

What are the main features of the Televes INNOVA 130220 antenna?
High dynamic range: It allows high-quality TV reception in a wide variety of critical situations, from areas where signals are very weak to installations with high reception levels
A more stable reception: supports signal variations or fading without any impact on the TV installation
Plug & Play: Easy and fast installation
Multiple power supply options:
Through the 5V USB port of the TV (USB-microUSB cable included)
With a conventional USB power supply unit
Simply using a receiver (through the RF output connector)
Low power consumption in intelligent mode
LTE-Ready: equipped with LTE filters to avoid mobile phone signals
Two operation modes:
In intelligent mode (with antenna feeding), BOSS provides automatic control to correct signal fluctuations and maintain optimal output signal level
In passive mode (without power supply), the signal goes through
The electronics inside the antenna substantially reduces the interference caused by surrounding movements
Thanks to be an omnidirectionial antenna, it can be installed either in horizontal or in vertical position
What technical specifications does the Televes INNOVA 130220 antenna have?
?Frequency bands LTE700 MHz 470 – 694
?Channels No. 21-48
?Gain dBi 20*
?Noise figure dB 3
?Power supply /
?Consumption USB V/mA 5/60
Coax. 12/60
?Protection index IP 20
