M16 Grade 80 High Tensile Lifting Eye Nut
KSh12,600.00
Description
M16 Grade 80 High Tensile Lifting Eye Nut
The M16 Grade 80 High Tensile Lifting Eye Nut is a robust and reliable lifting component designed for heavy-duty applications. Made from high tensile steel, this eye nut is engineered to meet Grade 80 standards, ensuring exceptional strength and durability under demanding conditions. With a metric thread diameter of 16mm, it is compatible with standard M16 fittings, making it a versatile choice for various lifting and rigging tasks.
This eye nut features a hot-dip galvanized or powder-coated finish, providing excellent corrosion resistance to withstand harsh environmental conditions. It is designed with a minimum working load limit (WLL) typically around 2,500 kg (5,500 lbs), offering a safe and secure solution for lifting operations. The eye diameter is adequately sized to allow for easy attachment of lifting equipment, facilitating quick and efficient connections.
The forged construction of the M16 lifting eye nut guarantees reliability and strength, with a minimum safety factor of 4:1 based on the working load limit. It is suitable for use in a wide range of industries, including construction, shipping, and manufacturing, where secure lifting and rigging solutions are crucial.
Additionally, this eye nut can operate in extreme temperature ranges, typically from -40°C to +200°C, making it ideal for various environmental conditions. It complies with international lifting standards, such as EN 1677-4, ensuring safety and performance during lifting operations.
