Mercury 6KVA UPS, 6000KVA Online UPS

Related products

•

  Mercury HIP33020S 20kVA (18KW) 3 Phase Online Tower UPS

  KSh903,500.00

  Description
  Mercury HIP33020S 20kVA (18KW) 3 Phase Online Tower UPS

  ECO mode -Programmable monitoring -Common/Separate battery – DSP controlled technology – Superior overload capability – Programmable control software – Parallel redundancy up to 4 units – Versatile communication interfaces -High power density for space saving – Megatec/Modbus protocol supported -Output power factor at 0.8 (0.9 optional) -Unity power factor and low input distortion – Programmable battery and build-in charger – Wide input voltage and frequency windows

  20kVA (18KW) 3 Phase Online Tower UPS specifications
  Mercury online HIP33020S UPS, 0.8/9PF
  20KVA/18KW
  3/3 phase
  ±120VDC (2*20*9AH/12V battery)
  input/output battery terminal
   RS232/RS485 communication interface
  Capacity: 20kVA (kilovolt-ampere)
  Power Rating: 18kW (kilowatts)
  UPS Topology: Online Double Conversion
  Input Voltage: 3-Phase, 380/400/415VAC
  Output Voltage: 3-Phase, 380/400/415VAC
  Frequency: 50/60Hz
  Efficiency: High efficiency at full load and partial load
  Battery Type: External batteries required for extended runtime (not included)
  Communication Ports: RS232, USB, SNMP
  Display: LCD or LED display for status and parameters monitoring
  Protection Features: Overload protection, short circuit protection, surge protection, voltage regulation, frequency regulation, etc.
  Backup Time: Varies depending on the load and battery configuration
  Form Factor: Tower configuration
  Dimensions: (H x W x D) – Varies based on the specific model
  Weight: Varies based on the specific model
  Certifications: CE, RoHS

  The Mercury HIP33020S 20kVA (18KW) 3 Phase Online Tower UPS is a high-performance uninterruptible power supply designed for critical power protection in three-phase environments. With its online double conversion topology, it provides reliable and continuous power to connected equipment by filtering out power disturbances and delivering clean, stable power.

  Add to cart

  Quick View
•

  Mercury Envy 3KVA UPS, 2.7KW Rackmount/ Tower Smart Ups

  KSh97,000.00

  Description
  Mercury Envy 3KVA/2.7KW Rackmount/Tower Smart Ups

  Mercury Envy 3KVA/2.7KW Rackmount/Tower Smart Ups is a reliable alternative power source. It is your perfect backup in the events of a power outage to keep your devices running.

  When there is a power cut, this UPS automatically switches over with zero downtime. Mercury Envy Rackmount & Tower Convertible UPS protects your electronic equipment from damage due to power outages, surges, and spikes while providing short term battery power during an outage.

  Mercury Envy 3KVA/2.7KW Rackmount/Tower Smart Ups features Automatic Voltage Regulation (AVR), which instantly adjusts high and low voltage fluctuations to safe levels for your electronics, saving battery power for when you need it most during storms and power outages.

  Mercury 3KVA Rackmount UPS Specifications
  Capacity: 3KVA (3000VA)
  Power Rating: 2.7KW (2700W)
  Rackmount/Tower convertible design for flexible installation options
  LCD display for real-time UPS status monitoring
  Pure sine wave output for clean and stable power delivery
  Advanced DSP digital control technology for enhanced performance and reliability
  Wide input voltage range for compatibility with various power sources
  Automatic voltage regulation (AVR) to stabilize voltage fluctuations
  Hot-swappable batteries for easy maintenance and uninterrupted power supply
  Intelligent battery management system to prolong battery life
  Built-in surge and overload protection to safeguard connected devices
  Audible alarms and LED indicators for easy status notification
  USB and RS232 communication ports for remote monitoring and management
  Compatible with the UPSilon2000 software for advanced control and configuration
  Supports generator compatibility for additional backup power options
  Energy-saving mode to optimize efficiency and reduce power consumption
  Designed for reliable and continuous operation in demanding environments.

  Conclusions

  The Mercury Envy 3KVA UPS is a high-performance power backup solution with a capacity of 3000VA (3KVA) and a power rating of 2.7KW (2700W). Its rackmount/tower convertible design allows for flexible installation options, making it suitable for various setups.

  The UPS features an LCD display that provides real-time monitoring of its status, ensuring you stay informed about its performance. With pure sine wave output, it delivers clean and stable power to protect your sensitive equipment.

  Add to cart

  Quick View
•

  Mercury 20kva/18kw 3 Phase Online Ups

  KSh590,000.00

  Description
  Mercury 20kva/18kw 3 Phase Online Ups

  Mercury 20kVA 3-Phase in / 3-phase out Online UPS EP20K offers the large UPS capacity a user may want, but also the 3-Phase input-output specification that may be required for some installations.

  Still, the Mercury 3-phase 20kVA online UPS brings advanced features and the superb quality and decent pricing that Mercury UPS products have stood out for. Mercury UPS series offers the best quality-price fit, giving you the opportunity to acquire high performance power backup systems at the best market price.

  The Mercury EP20K 20kVA Online UPS Power rating of 18kW and a battery voltage of 384VDC. It is a high efficiency UPS and suitable for critical installations.

  View the specifications of the 20kVA 3-phase in – 3-phase out Mercury UPS EP20K
  Capacity: 20kVA (kilovolt-ampere)
  Power Rating: 18kW (kilowatts)
  UPS Topology: Online Double Conversion
  Input Voltage: 3-Phase, 380/400/415VAC
  Output Voltage: 3-Phase, 380/400/415VAC
  Frequency: 50/60Hz
  Efficiency: High efficiency at full load and partial load
  Battery Type: External batteries required for extended runtime (not included)
  Communication Ports: RS232, USB, SNMP
  Display: LCD or LED display for status and parameters monitoring
  Protection Features: Overload protection, short circuit protection, surge protection, voltage regulation, frequency regulation, etc.
  Backup Time: Varies depending on the load and battery configuration
  Form Factor: Rack-mount or tower configuration options available



  Output :
  Phase 3 Phase 4 Wire (3ph+N+PE)
  Rated Voltage 380 / 400 / 415VAC
  Rated Power Factor 0.9
  Frequency 50Hz/60Hz ±0.5Hz (Battery Mode)
  50/60 (1±1/2/4/5%)Hz (On-Line)
  Voltage Precision Output Balanceable:±1.0%; Output Non-Balanceable:±3.0%
  THD Linear Load: ≤2.0%; Non-Linear Load: ≤4.5%
  Overload Capability 110% for 60mins; 125% for 10mins; 150% for 1min
  Crest Factor ≥3 : 1
  Waveform Sine Wave
  DC Component ≤500mVDC
  Output Current 24A / 36A / 48A / 72A / 96A (380V – Full Load)
  23A / 35A / 46A / 70A / 94A (400V – Full Load)
  22A / 33A / 44A / 66A / 88A (415V – Full Load)
  Input :
  Rated Voltage 380 / 400 / 415VAC
  Voltage Range Po≤69%: 208±5VAC~478±5VAC
  Po≥69%: 304±5VAC~478±5VAC
  Frequency 40±0.5Hz~70±0.5Hz
  Input Phase 3 Phase 4 Wire (3ph+N+PE)
  THDi Input THD≤1.0%, Linear Load: ≤3.0%
  Input THD≤1.0%, Non-Linear Load: ≤7.0%
  Power Factor >0.99
  Battery :
  Model Sealed Lead Acid Battery (VRLA)
  Configurable Battery 32 (Not included, purchased separately)
  Discharge Current (320VDC) 54A / 81A / 106A / 160A / 213A
  Charge Current (Max) 20/30KVA 40/60/80KVA
  15A 30A
  System :
  Efficiency ≥90% (Line Mode)
  ≥93% 20/30KVA , ≥94% 40/60/80KVA (Battery Mode)
  ≥97% (ECO Mode)
  Wasting ≤3% (Line Mode)
  ≤2% (ECO)
  Noise at 1M <56dB Running Temperature 0~40˚C Relative Humidity 0%RH~95%RH (Non-condensing) Altitude 1000m Output Normal Power Display LCD+LED Breaker/ Fuse 40A / 63A / 80A / 125A / 160A Remote Signaling Dry Contact Communication RS232/RS485/SNMP MTBF Inverter MTBF >50,000 Hours
  Single Modules MTBF >250,000 Hours
  1+1 Expandable Modules MTBF >400,000 Hours
  MTTR The MTTR of Each Single UPS Modules is Lower 30mins
  Dielectric Resistance > 2MΩ (500VDC)
  Dielectric Strength 2820VDC, Leak Current<3.5mA, 1min Vibration Impact Fulfill standard ISTA (International Safe Transmission Association) 1B Transportation Fulfill standard ISTA (International Safe Transmission Association) 1B Degree Of Protection Ip20 Net/Gross Weight (kg) 242/266 Dimension(WxDxH) mm 930 x 700 x 1390 Bypass : Voltage Range 380V 208/266/304±5VAC~399/418/437/475±5VAC 400V 220/280/320±5VAC~420/440/460±5VAC 415V 228/290/332±5VAC~436/457/477±5VAC Frequency Range 50(1±10%)Hz / 60(1±10%)Hz Phase 3 Phase 4 Wire (3ph+N+PE) Overload Capability 125%~170% for 10mins Eco Mode : Voltage Range 380V 304±5VAC~399 / 418±5VAC 400V 320±5VAC~420 / 440±5VAC 415V 332±5VAC~436 / 457±5VAC Frequency Range 50(1±10%)Hz / 60(1±10%)Hz Phase 3 Phase 4 Wire (3ph+N) Model EP20K Capacity 20kVA  Power 18KW Maximum Input Current 40A / 63A / 80A / 125A / 160A

  Add to cart

  Quick View
•

  Mercury 10KVA /8KW Online Smart UPS

  KSh288,000.00

  Description
  Mercury 10KVA/8KW Online Smart UPS

  Mercury 10KVA/8KW Online Smart UPS is a reliable alternative power source. It is your perfect backup in the events of a power outage to keep your devices running.

  When there is a power cut, this UPS automatically switches over with zero downtime. Mercury online HP9110C-S 0.8PF protects your electronic equipment from damage due to power outages, surges, and spikes while providing short term battery power during an outage.

  Mercury 10KVA/8KW Online Smart UPS Features Automatic Voltage Regulation (AVR), which instantly adjusts high and low voltage fluctuations to safe levels for your electronics, saving battery power for when you need it most during storms and power outages.

  Mercury 10KVA UPS Specifications
  Power Rating: 10KVA/8KW
  UPS Topology: Online Double-Conversion
  Input Voltage Range: 176V – 276V
  Input Frequency Range: 46Hz – 54Hz (Auto-sensing)
  Output Voltage: 220V/230V/240V (Selectable)
  Output Frequency: 50Hz/60Hz (Auto-sensing)
  Efficiency: ≥ 90%
  Crest Factor: 3:1
  Waveform: Pure Sine Wave
  Battery Type: Sealed Maintenance–Free Lead-Acid
  Battery Voltage: 240VDC
  Backup Time (Full Load): Approximately 5-10 minutes
  Backup Time (Half Load): Approximately 10-20 minutes
  Recharge Time: 6-8 hours to 90% capacity
  Communication Ports: USB, RS232
  Operating Temperature: 0°C to 40°C
  Relative Humidity: 0% to 95% (non-condensing)
  Audible Noise: <50dB Dimensions: (H x W x D) 480mm x 250mm x 660mm Weight: Approximately 55kg

  Add to cart

  Quick View
•

  Mercury 10KVA UPS, 10000KVA Online UPS

  KSh270,000.00

  Description
  Mercury 10KVA (10000KVA UPS) Online UPS | Kenya

  Mercury 10KVA (10000KVA UPS) Online UPS has a power rating of 7000W which can support a significant number of equipment, providing the power backup needed by such sensitive equipment.

  Mercury 10KVA Online UPS range is ideal for mission-critical IT equipment like servers, network systems, workstations, PCs, etc. Because they deliver clean quality pure sine wave power, you have reliable power quality to support your sensitive IT equipment.

  Mercury 10000KVA online UPS ensures that the zero tolerance for any break in power supply, which is imperative for highly sensitive applications, is what you get. With zero switching time, Mercury 10000KVA online UPS ensures your equipment is kept supplied and running, without service disruptions, at power failure from the grid.

  10KVA online Mercury UPS offers a perfect balance between top performance, reliability and budget-friendly pricing, the Mercury 10KVA online UPS range has an outstanding rating.

  10000KVA Mercury online UPS systems have continued to support mission critical equipment in many organisations in Kenya The rated capacity of the 10kVA Mercury Online UPS, which is 7000W, can support multiple office devices.

  The estimated backup time at half-load is 13 minutes, and that comes down to about 5 minutes backup at full load, with possible extension, optionally. Mercury 10kVA Online UPS is powered by 20 x 8.2AH / 12V internal battery pack. You can extend backup with the optional extension battery pack.

  Mercury 10kVA Online UPS specifications from Mtech Networks
  Power 10kVA / 7000W
  Voltage range 176 ±5VAC~276 ±5VAC
  Frequency 46~54Hz ±0.5Hz, or 56~64Hz ±0.5Hz auto sensing
  Input phase Single phase
  Power factor **0.98
  Voltage range 220VAC ±1%
  Output phase Single phase
  Frequency 50Hz ±0.2% (battery mode)
  THD < 2% (Linear load); < 6% (non-Linear load) Overload 105%~130% 10min turn to Bypass mode, > 130% 1s turn to Bypass mode
  Crest factor 3:1 (max)
  Waveform Pure sine wave
  Transfer time 0ms (AC mode – Battery mode) 0ms (AC mode – Bypass mode)
  Efficiency **88%
  AC mode 5 cycles turn off inverter, no transfer to Bypass, provide alarm.
  Battery mode 5 cycles turn off inverter, provide alarm.
  Bypass mode Input fuse blown or break action.
  Battery Model 12V sealed lead acid maintenance free
  DC voltage 240VDC
  Configuration 20 x 12V/8.2AH
  Backup time 13min (half load) / 5min (full load)
  Charge current 1A (standard unit) / 5A (long time unit)
  Recharge time 90% capacity after 8hrs charging
  Communication Interface RS232; SNMP (optional)
  Parallel Port Parallel availability for redundancy and load sharing up to three unit
  LCD Indication Input voltage/frequency; battery voltage; output voltage/frequency; load watt/VA value & percent; inverter temperature; operation mode such as “on batt” or “on bypass”
  LED Indication Green: normal operation; Yellow: warning condition Red: abnormal operation
  Noise level ** 55dB
  Temperature 0~40**C; 0 ~ 40**C (storage temperature)
  Humidity 0~95% (non-condensing)
  Altitude < 1500m Weight Net/Gross 92/107kg (standard unit); 36/51kg (long time unit) Dimension (WxDxH) 270 x 570 x 720mm Packaging (WxDxH) 370 x 670 x 940mm Best Online UPS in Kenya Mercury UPS dealer in Nairobi Mercury 6KVA UPS price in Kenya Mercury 650VA UPS Kenya

  Add to cart

  Quick View
