MikroTik hEX PoE
5x Gigabit Ethernet with PoE output for four ports, SFP, USB, 800MHz CPU, 128MB RAM, RouterOS L4
hEX PoE is a five port Gigabit Ethernet router for locations where wireless connectivity is not required. The device has a USB 2.0 port and a SFP port for adding optical fiber connectivity. The ports 2-5 can power other PoE capable devices with the same voltage as applied to the unit. It is affordable, small and easy to use, but at the same time comes with a very powerful 800MHz CPU, capable of all the advanced configurations that RouterOS supports. Less power adapters and cables to worry about! Max current is 1A per port, Ethernet ports are shielded. It also supports passive PoE input and passive or 802.3af/at PoE output. Ethernet ports 2-5 can power other PoE capable devices with the same voltage as applied to the unit. Less power adapters and cables to worry about! It can power at/af mode B (4,5+)(7,8-) compatible devices, if 48-57 input voltage is used.  Send purchase questions Specifications Support & Downloads Gallery Test results Specifications Details Product code RB960PGS Architecture MIPSBE CPU QCA9557 CPU core count 1 CPU nominal frequency 800 MHz Switch chip model QCA8337 RouterOS license 4 Operating System RouterOS Size of RAM 128 MB Storage size 16 MB Storage type FLASH MTBF Approximately 100’000 hours at 25C Tested ambient temperature -40°C to 60°C Suggested price $89.00 Powering Details Number of DC inputs 2 (DC jack, PoE-IN) DC jack input Voltage 12-57 V Max power consumption 54 W Max power consumption without attachments 6 W Cooling type Passive PoE in Passive PoE PoE in input Voltage 12-57 V PoE-out Details PoE-out ports Ether2-Ether5 PoE out 802.3af/at Max out per port output (input 18-30 V) 1 A Max out per port output (input 30-57 V) 450 mA Max total out (A) 2 A Ethernet Details 10/100/1000 Ethernet ports 5 Fiber Details SFP ports 1 Peripherals Details Number of USB ports 1 USB Power Reset Yes USB slot type USB type A Max USB current (A) 1 Other Details PCB temperature monitor Yes Voltage Monitor Yes Beeper Yes Certification & Approvals Details Certification CE, EAC, ROHS IP IP20 Included parts 24V 2.5A power adapter IEC cord The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.. Related products XS+2733LC15D $349 S+AO0005 $49 S-55DLC80D $39 XS+DA0003 $39 S-31DLC20D $29.00 XS+DA0001 $29 S-RJ01 $29.00 S+85DLC03D $59.00 48V2A96W $39 S-85DLC05D $22.00 S-3553LC20D $79.00 S-4554LC80D $89
