Optical Splitter 1310…1550nm SC/APC 2D 4dB Televes
KSh44,126.00
Passive optical splitters: 2 outputs, to be used in optical fibre star networks.**Optical Splitter 1310/1550nm SC/APC 2D 4dB Televes 2337
Passive optical splitters: 2 outputs, to be used in optical fibre star networks.
Specifications
Reference? 2337
?No. of outputs?? ?2
?
?
INPUT / OUTPUT
?
?
? ?Wavelength nm 1310 – 1550
?Optical connector? ?SC/APC
?Insertion losses 1310/1550 nm ?dB ?? 4.1
?Uniformity ?dB ??55
?Directivity ?dB ??55
?Return losses ?dB ?? 0.6
????
GENERAL
? ?Ingress protection level ?IP ?20
?Dimensions (WxHxD) ?mm ?50 x 216 x 175
