OTDR for Televes Singlemode 1310-1550nm Fiber Optic
OTDR for the Installation of Single-mode Fiber Optic Links 1310-1550nm Ref. 598001 from Televes
This device is used for the installation and maintenance of fiber optic networks. It is compatible with single-mode fibers of 1310/1550nm wavelengths.
It allows us to locate faults in the network quickly. It has a battery with a range of up to 8 hours of continuous use (and 20 hours on standby). It is a portable OTDR, small in size, very comfortable to transport. It has a 5? touch screen that makes it much easier to use and carry out operations.
Among the functions it performs are: automatic OTDR, expert OTDR mode, link image, optical power meter, stabilized laser source, optical loss test and visual fault locator.
It features short range performance with 1.5m event dead zone and 8m attenuation dead zone.
OTDR Technical Specifications for the Installation of Single-mode Fiber Optic Links 1310-1550nm Ref. 598001 from Televes
Reference: 598001
Logic Ref: OTDRBASIC
EAN13: 8424450283714
Physical data
Net weight 700.00 g
Gross weight 700.00 g
Width 190.00 mm
Height 130.00 mm
Depth 65.00 mm
?
wavelength 1310/1550nm ? 20nm
Dynamic range (2) 24/22dB
Event dead zone (3) 1.5m
Damping dead zone (3) 8 m
Distance range 0.5, 1, 2, 4, 8, 16, 32, 64, 100 km
Pulse width 3 – 2000 ns
averaging time 5, 15, 30, 60, 120, 180s
Accuracy distance measurement ? (1m + 5?10^-5 ? distance + sampling resolution)
Accuracy insertion loss ?0.05dB/dB
Return loss accuracy ?3dB
sampling resolution 0.05 – 8 m
Refractive index (IOR) 1,00000 – 2,00000
Resolution attenuation measurement 0.001dB
Minimum threshold for detecting non-reflective events 0.01dB
Measuring port stretch connector type SC/UPC
?
General specifications
display 5-inch color LCD, multi-touch capacitive touchscreen
Power supply Lithium battery: 3.7 V, 6600 mAh
Power supply: 5V DC, 2A
Battery life 8 hours continuous operation, 20 hours standby
Storage capacity 8Gb, ? 200,000 records
Data interface USB Type C
operating temperatur -10?C ~ 50?C
Storage temperature -40?C ~ 70?C
Relative humidity 0 – 95% (non-condensing)
Weight 0.7 kg (including battery)
Dimensions (H?W?D) 190 ? 130 ? 65mm
?
Visible Laser Light Source (VFL)
wavelength 650nm ?20nm
Output power ? 10mW
MOD CW/1Hz/2Hz
Measuring port stretch connector type Universal 2.5mm
?
Stabilized Laser Light Source (SLS)
wavelength 1310/1550nm ? 20nm (4)
Output power ? -5 dBm (adjustable)
MOD CW/ 270Hz/ 330Hz/ 1KHz/ 2KHz
stability CW ? 0.5 dB (after 15 min preheating time)
Measuring port stretch connector type FC/UPC
?
Optical Power Meter (OPM)
Calibrated wavelength 850, 1300, 1310, 1490, 1550, 1625, 1650 nm
Performance range -50 – +26dBm
Detector type InGaAs
Resolution attenuation measurement 0.01dB
Accuracy of attenuation measurement ?5%
Frequency detection CW/ 270Hz/ 330Hz/ 1KHz/ 2KHz
Measuring port stretch connector type universal 2.5mm
?
Optical Attenuation Test (OLT)
Stabilized laser light source Same as SLS module
Optical power meter Same as OPM module
Detector type InGaAs
Resolution attenuation measurement 0.01dB
Accuracy of attenuation measurement ?5%
Frequency detection CW/ 270Hz/ 330Hz/ 1KHz/ 2KHz
Measuring port stretch connector type universal 2.5mm
?
Technical data
longitud de onda
1310/1550 nm ? 20 nm
Rango din?mico (2)
24/22dB
Zona muerta del evento (3)
1,5 metros
Zona muerta de amortiguaci?n (3)
8 metros
Rango de distancia
0,5, 1, 2, 4, 8, 16, 32, 64, 100 kil?metros
Pulsbreita
3 – 2000 ns
tiempo promedio
5, 15, 30, 60, 120, 180 segundos
Medici?n de distancia de precisi?n
? (1m + 5?10^-5 ? distancia + resoluci?n de muestreo)
P?rdida de inserci?n de precisi?n
? 0,05dB/dB
Precisi?n de p?rdida de retorno
? 3dB
resoluci?n de muestreo
0,05 – 8 metros
?ndice de refracci?n (IOR)
1.00000 – 2.00000
Medici?n de atenuaci?n de resoluci?n
0,001dB
Umbral m?nimo para detectar eventos no reflectantes
0,01dB
Tipo de conector el?stico del puerto de medici?n
SC/UPC
