Shunt with flange 6 outputs (24dB)
**Shunt Type 6 Outlets 6B 24dB Televes.
6-lead shunt with EasyF Connection System
This splitter is ideal for SMATV (Community Antenna and Television System) signals. Its compact design and efficient performance make it a great choice for distributing signals in buildings.
Highlights:
EasyF Connection:**Makes installation super easy and fast.
Bypass Loss:**With 24dB bypass loss, it is perfect for 4th and 5th floors, ensuring a strong and stable signal.
Compact Design:**Easily fits indoors without taking up much space.
Electronic Efficiency:**Offers top performance with minimal signal loss for better quality transmission.
Recommendations:
Indoor Installation:**Best indoors to protect from the elements.
Presentation:**Comes in boxes of 6 units, easy to handle and store.
Technical Specifications of the 6-Output Shunt Type 6B 24dB. Ref. 5494 from Televes.
Frequency range MHz 5 … 2400
Number of derivations ? 6
Floors ? 4 and 5
Tickets/Bands ?
TERR SAT
Step losses dB
3 4
Bypass losses dB
24 24
Rejection between derivation dB
> 45 > 45
Connectors ? Type “EasyF”
Max voltage V 40
Max current mA 300
DC Step ? Sal.?Entr.
