Skill Tech SH 1016P Heavy-Duty Full-Motion TV Wall Mount With Long Arm Extension
SH 1016P
Heavy-Duty Full-Motion Tv Wall Mount With Long Arm Extension
Product Category:
Full-Motion TV Wall Mount
Rank: Standard
Material: Steel
Metal Sheet Thickness: Bracket Arm THK=1.5mm cold-rolled sheet,VESA Panel
THK=1.5mm cold-rolled sheet,Wall Plate THK=3mm pickling sheet (Bracket Arm
THK=0.059″ cold-rolled sheet,VESA Panel THK=0.059″ cold-rolled
sheet,Wall Plate THK=0.12″ pickling sheet)
Pipe Size: 40x25x1.5mm Square Steel Tube,50x25x1.5mm Square Steel Tube
(1.6″x0.98″x0.059″ Square Steel
Tube,2″x0.98″x0.059″ Square Steel Tube)
Surface Finish: Powder Coating
Color: Fine Texture Black
Dimensions: 1044x885x430mm (41.1″x34.8″x16.9″)
Fit Screen Size: Suitable For Most 43″ ~ 90″ Screen
Fit Curved TV: Yes
Mounting Hole Pattern : VESA Only
Max.VESA: 800x400mm
Weight Capacity: 80kg (176lbs)
Strength Tested:
3 Times Approved
Profile: 69-1044mm (2.7″~41.1″)
Tilt Range: +5° ~ -15°
Swivel Range: +60° ~ -60°
Screen Level: +3° ~ -3°
Screen Freely Tilting: Yes
Installation: Solid Wall,Double Stud(406mm/450mm/600mm)
Panel Type: Detachable Panel
Wall Plate Type: Fixed Wall Plate
Direction Indicator: Yes
Cable Management: Yes
Bubble Level: Hook-on Bubble Level(Included in Components Package)
Accessory Kit Package: Compartment Polybag
The SH 1016P Heavy-Duty Full-Motion TV
Wall Mount with Long Arm Extension is a robust and versatile mounting
solution for your TV. Built with high-quality steel and featuring a durable
powder-coated finish in fine texture black, this wall mount is designed to
last. It accommodates a wide range of TV sizes, suitable for screens from 43
to 90 inches, including curved TVs. The mounting hole pattern supports VESA
standards, with compatibility for sizes such as 200×200, 300×200, 400×200,
300×300, 400×300, 400×400, 600×400, and 800x400mm, with a maximum mounting
hole size of 800x400mm.With a remarkable weight capacity of 80kg (176lbs),
this wall mount has undergone rigorous strength testing, receiving approval
three times over to ensure the safety of your TV. The adjustable profile
ranges from 69mm to 1044mm (2.7″~41.1″), allowing you to achieve
the perfect viewing height and customize the placement according to your
preferences. It offers a tilt range of +5° to -15°, enabling you to adjust
the screen angle for an optimal viewing experience. The impressive swivel
range of +60° to -60° provides flexibility in positioning the TV at various
angles, and the screen level feature, with a range of +3° to -3°, ensures
precise alignment.This wall mount also supports screen freely tilting for
added convenience. Installation options include solid wall and double stud
(406mm/450mm/600mm), providing flexibility to suit your needs. The panel is
detachable for easy setup, and the wall plate type is fixed for stability.
Additional features include a direction indicator and cable management to
keep your setup organized and a hook-on bubble level included in the
components package for accurate installation. Elevate your home theater
experience with this heavy-duty, long-arm extension TV wall mount.
