T.0X Optical Amplifier 1i/1o: 1550nm SC/APC 20dBm Televes
KSh914,276.00
The module amplifies the 1550 nm optical signal producing an optical output power of 20 dBm. Based on EDFA (erbium doped fibre) technology, it provides a high gain and a low noise factor.
1-output EDFA optical amplifier
1550 nm, Po 20 dBm
The module amplifies the 1550 nm optical signal producing an optical output power of 20 dBm. Based on EDFA (erbium doped fibre) technology, it provides a high gain and a low noise factor.
Highlights
-3 dBm to +10 dBm input range
Status LED indicators
?Features
Optical amplification for the RF service over fibre (RF Overlay)
Suitable for long distances
SC/APC connectors
Specifications
Optical bandwidth nm 1550 ?15
Input optical power dBm -3 … +10
Output optical power dBm 20 ?0.8
Noise figure dB < 5
Return losses dB > 50
C/N dB > 53
CSO – CENELEC 42 CH dBc > 61
CTB – CENELEC 42 CH dBc > 61
Powering V= 24 ?5%
Max. current consumpt mA 300 @24V=
Optical connectors Type SC/APC
Operating temperature
?C
?F
-5 … +45
+23 … +113
Protection index IP 20
Application example
