Televes 4GNova Antenna Terrestrial 4G/LTE (N Female)
KSh23,178.00
Antenna transmission and reception of LTE / 4G signals for extending coverage shielded or difficult propagation areas. The 4GNova antenna can directly connect to an LTE / 4G router or a radiant indoor antenna.
Antenna transmission and reception of LTE / 4G signals for extending coverage shielded or difficult propagation areas. The 4GNova antenna can directly connect to an LTE / 4G router or a radiant indoor antenna. In the latter case, the devices can use the 4G network coverage obtained without issuing high power, saving battery and protecting the user from excessive radiation.
Features
4G mobile devices more efficient.
Wide frequency range.
Aesthetic design and noninvasive.
Reply optimized links uplink and downlink.
High quality antenna made of high strength materials.
Its implementation in printed circuit prevents changes in mechanical characteristics and quality guarantees.
Easy intalacion on balconies and facades. No maintenance required.
No consumption.
Technical specifications
Conectores N hembra
Banda de trabajo ?698…960 Mhz
1700…2700 Mhz
Ganancia 7,5 dBi
7 dBi
Relaci?n D/A >18 dB
>20 dB
Impedancia 50?
Carga al viento 69,6 N (@130Km/h)
95,7 N (@150Km/h)
Dimensiones (Anc x Al x Pr) 420 x 315 x 75 mm
?ndice de protecci?n IP53
?Peso 1.5 kg
Application example
* see Attachments for more mounting information
Radiation diagram
