Televes Multiswitch 17x17x8 F Terminal/Cascade Nevoswitch
KSh121,964.00
13x and 17x multiswitch range with 8 outputs with available through outputs to connect**several multiswitches in cascade configuration and therefore**extend the number of users.
SCALABLE 13X AND 17X MULTISWITCHES RANGE
EUROPEAN QUALITY AND DESIGN
THE BEST CHOICE FOR IRS SYSTEMS
13x and 17x multiswitches range with 8 outputs with available through outputs to connect?several multiswitches in cascade con guration and therefore?extend the number of users.
Switch to choose between star and cascade configuration.
Both ranges feature a 13 wires amplifier (12 satellite plus?terrestrial) and 17 wires amplifier with 25dB preaccentuated?gain on satellite and 25dB gain on terrestrial with through?powering.
Highlights:
Radiation inmune thanks to its zamak made chassis.
All switch references are valid for standalone, star or cascade?configuration.
Selectable IF gain (+10 dB) for each group or 8 users to balance the?output signals.
Multiple powering options: mains and line powered.
ECO mode: the overall consumption is reduced as the number of?users decreases.
Features
Small sized design: Make the most of space to accomodate?more TV subscribers.
Use the same multiswitch in either star/cascade or standalone?configuration.
Independent amplification of every feed (8 satellite plus?Freeview).
Multiple powering options: mains and line powered.
Adjustable gain and equalization to achieve the best?performance for every system’s requirements.
Specifications
Reference ?714801
?Type 17x17x8
?Frequency range ?MHz ?SAT 950 … 2400
?TER 88 … 862
?RP 5 … 65
?Input level ?dB?V ?SAT 112
?TER? 90
?Through losses ?dB ?SAT? 2 … 5
?RF 2
?RP 3
?Tap losses
?1…8 / 9…16 / 17…24 / 25…32 dB ?SAT1 3/-/-/-
?RF 4/-/-/-
?RP 34/-/-/-
?Isolation ?dB H/V >30
Users >25
?DC Pass In-Out / Out-In
?Max. total consumption mA? ?PSU Low Gain2 45
High Gain2 90
?Receiver? 40
?Temperature range ??C? -5…+45?C
?Protection level ?IP? IP20
?Weight ?g 1100
?Dimensions ?mm? 350x120x30
(1) LG – 10 dB
(2) if output charged => + 85mA
DATA SHEET
