Tiandy 2MP 25X IR PTZ Camera

Product
Description

Camera







Image Sensor

1/2.8″CMOS

Min. Illumination

Color:0.001lux@ (F1.5,AGC ON),B/W:0lux with IR

Shutter Time

1s~1/100000s

Day&Night

IR-cut filter with auto Switch (ICR)

Smart IR

Yes

WDR

120dB

S/N

42dB

Lens







Focal Length

4.8mm~120mm

Optical Zoom

25X

Digital Zoom

16X

Zoom Speed

<5s

Aperture Range

F1.5~F3.8

Aperture Type

Auto(P-Iris)

Field of View

58.5°~2.8°(H); 33.2°~1.5°(V); 65.2°~3.3°(D)

Focus Control

Auto/Semi-auto/Manual

Close Focus Distance

200mm~1500mm

DORI Distance

Detect:1517m Observe:602m Recognize:303m Identify:151m

Pan&Tilt







Pan Range

360°

Pan Speed

Manual Speed:0.1°?200°/s Preset Speed:240°/s

Tilt Range

-16°~90° (Default -3°~90°)

Tilt Speed

Manual Speed:0.1°?120°/s Preset:180°/s

3D Position

Yes

Preset

500

Cruise

16,up to 32 presets per cruise

Scan

8

Pattern

8,each with 600s memory or 1000 orders

Scheduled Task

Preset,Cruise,Scan,Pattern

North Point

Yes(Manual setting)

Power-off Memory

Yes

Illuminator







IR LEDs

6

IR Distance

Up to 150m

Wavelength

850nm

IR Irradiation Angle

Yes

Compression Standard







Video Compression

S+265/H.265/H.264B/H.264M/H.264H/Motion JPEG

Video Bit Rate

32Kbps~16Mbps

Audio Compression

G.711A/G.711U/ADPCM_D/AAC_LC

Audio Sampling Rate

8KHz/32KHz/48KHz








Max. Resolution

2MP,1920×1080@30fps

Main Stream

PAL:25fps(1920×1080,1280×720,640×480,704×576)
NTSC:30fps(1920×1080,1280×720,640×480,704×480)

Sub Stream

PAL:25fps(704×576,704×288,640×360,352×288)
NTSC:30fps(704×480,704×240,640×360,352×240)

Third Stream

PAL:25fps(352×288) NTSC:30fps(352×240)

BLC

Yes

HLC

Yes

AGC

Yes

3DNR

Yes

White Balance

Auto/Semi-Auto/Manual/Sunshine/Nature Light/Warmlight Lamp/Daylight
Lamp/Filament Lamp/Lock White Balance

ROI

7 rectangular 3D fixed focus areas,supporting 1 rectangular dynamic
tracking ROI

OSD

5 regions(Each region can have a maximum of 127 characters ,up to 5 lines);
16*16/24*24/32*32/48*48/64*64/adaptable size; Vector/Lattice

Defog

Yes

Flip

Normal/Horizontal Mirror/Vertical Mirror/Inverted Flip

Regional Exposure

Yes

Regional Focus

Yes

Demist

Yes

Privacy Mask

24 regions(Up to 4 blocks in the same scene)

Feature







General Alarm

Motion Detection; Mask Alarm; Alarm Input

Exceptions Alarm

Voltage Alarm; Disk Full; Disk R/W Error; Recording Exception; IP Address
Conflict; MAC Address Conflict; FTP Server Exception ; Network cable
disconnected

Linkage Method

Send Email; Trigger Sound; Trigger Recording; Trigger Capture; Notify
Surveillance Center; Alarm Output

Video Analytics

Human/Vehicle Classification; Tripwire; Double Tripwire; Perimeter; Object
Abandon; Object Missing; Heatmap; Loitering; Running; Parking; People
Counting; Crowed Detection; On Duty Detection; Video Abnormal; Audio Abnormal

Auto-Tracking

Yes

Face Mode

Face Capture

Face Capture Performance

60; 19; ?60m; Detect up to 32 faces at the same scene; Capture up to 16
faces at the same scene; Capture rate ?99%(continuous scene with 10 people or
less); Gender 85%,age (±5) 85%,mask 90%,glasses 85%,beard 80% (Less than 10
people in view)

Network







ANR

Yes

Protocols

HTTP; HTTPS; TCP/IP; UDP; UPnP; ICMP; IGMP; SNMP v1v2v3; DHCP; DNS; DDNS;
Easy DDNS; NTP; SMTP; TLS v1.2; SSL; 802.1x; QoS; IPv4; IPv6; PPPoE; SSH;
Unicast; Multicast; ARP; RTP; SRTP; FTP; SFTP

System Compatibility

P2P; ONVIF(Profile S/T/G/M); SDK; CGI; Milestone; RTSP; RTMP

Remote Connection

?7

User/Host

Up to 32 users. 4 user levels

Client

Easy7 VMS

Moblie Client

EasyLive Plus

Web

IE10+; Firefox52+; Edge89+; Safari11+; Chrome57+

Interface







Communication Interface

1*RJ45 (10/100Base-T)

Audio I/O

1*Input; 1*Output

Alarm I/O

1*Switching; 1*Switching,Voltage?DC24V,Current?1A

Reset Button

Yes

On-board Storage

Built-in Micro SD card slot,up to 512 GB

General







Web Client Language

19 languages Simple Chinese/English/Traditional Chinese/Spanish/Italian/
Korean/Turkish/Russian/Thai/ Polish/French/Dutch/
Hebraism/Vietnamese/Arabic/German/ Ukrainian /Portuguese/Albanian

Operating Temperature

-30?~65?(-22?~149?)

Operating Humidity

?95%RH

Storage Temperature

-30?~65?(-22?~149?)

Storage Humidity

10%~95%RH(non-condensing)

Power Supply

DC12V±10%; PoE:IEEE 802.3at

Power Consumption

9W(IR OFF) ; 22W(IR ON)

Protection

Surge4000V; ESD6000V; IP66

Material

Metal

Boundary Dimensions

161mm(D)x276mm(H)

Package Dimensions

260(L)260(W)465(H)mm

GrossWeight

5.1Kg

NetWeight

3kg
