Triax KOKA F6 Plus PVC coaxial cable coil 250m white LTE

Triax?KOKA F6?Plus?is a premium cable for in-house installations. The wide frequency range allows the cable to carry signals for both television, radio, satellite receivers etc., whether the signal comes from satellite, terrestrial antenna or cable-tv.

This cable is designed with a center conductor of Copper Clad Steel (CCS) which offers high mechanical strength.
Due to the gas injected foam, which is far superior to the chemical foam, the copper cladding carries the signals without great losses.
A good quality conductor and appropriate gas injected dielectric grants velocity ratio higher than 80%.
The PVC material is UV protected, meaning the cable?stay white for a long time in sunny and warm weather conditions.
For outdoor installation we highly recommend the coax cables with PE jacket, as this material simply is more resistant to weather conditions.

CPR compliant – Fire class Eca according to the EN50575 fire standard

Specifications
ORDER INFORMATION
EAN Number 5702661511417
CONSTRUCTION
Dielectric – dimension 4.57 ? 0.1 mm
Dielectric – material PE foam
Jacket ? dimension 6.9 ? 0.2 mm
Jacket – material PVC
Shield (First) foil 1 ? material Al/Pet bonded
Shield (First) foil 1 ? overlap 20 %
Shield (Second) ? braid coverage 60 ? 3 %
Shield (Second) ? braid material Al
Third shield ? foil 2 ? material Al/Pet
Inner conductor – material CCS
Inner conductor – dimension 1.02 ? 0.03 mm
SHIELDING
Screening attenuation @ 1000-2000 MHz > 90 dB
Screening attenuation @ 2000-3000 MHz > 95 dB
Screening attenuation @ 30-1000 MHz > 100 dB
CHARACTERISTICS
Type KOKA F6 Plus
LOSS
Attenuation (at 20?C) @ 1000 MHz 21.5 dB
Attenuation (at 20?C) @ 1350 MHz 25.3 dB
Attenuation (at 20?C) @ 1750 MHz 28.4 dB
Attenuation (at 20?C) @ 200 MHz 9.0 dB
Attenuation (at 20?C) @ 2150 MHz 30.8 dB
Attenuation (at 20?C) @ 2400 MHz 32.9 dB
Attenuation (at 20?C) @ 3000 MHz 39.0 dB
Attenuation (at 20?C) @ 470 MHz 15.2 dB
Attenuation (at 20?C) @ 50 MHz 5.0 dB
Attenuation (at 20?C) @ 5 MHz 2.4 dB
Attenuation (at 20?C) @ 862 MHz 19.0 dB
RETURN LOSS
Structural return loss @ 1000-2000 MHz > 18 dB
Structural return loss @ 2000-3000 MHz > 16 dB
Structural return loss @ 470-1000 MHz > 21 dB
ELECTRICAL
Outer DC resistance < 38 ?/km Velocity ratio 81 % Impedance 75 ? 3 ? Inner DC resistance <100 ?/km OPERATIONAL Screening Efficiency EN50117 (Class A) Application Indoor Fire Class Eca DoP number TR0008 Notified Body 0051 MECHANICAL Packaging Depth 0001 m Packaging Height 0.001 m Total Weight 0.047 kg Packaging Width 0.001 m Length (m) 250 m Minimum bending radius - single/repeated 23/70 mm Net Weight 0.042 kg Tara Weight 0.005 kg Colour White Weight (kg) 12.75 Weight net 11.75
