Ubiquiti Networks U Fiber, OLT Managed None 1U Black (UF-OLT)
KSh227,827.85
Eight-port
GPON optical line terminal (OLT) designed to manage fiber internet service
for up to 1,024 clients (128 per port).
GPON. 2.488 Gbps down / 1.244 Gbps stream capacity
1024 Client capacity (8 ports)
(2) 10G SFP+ uplink ports
1U Rack mount
Power redundancy support
Ubiquiti
Networks U Fiber, OLT Managed None 1U Black
High-Performance GPON
Configuring a fiber network just became as easy as setting up a smartphone.
Say goodbye to command lines, manuals, and paid support licenses. Introducing
the U Fiber OLT – a fiber solution that anyone can deploy.
U Fiber offers Internet and telecom service providers a cost-effective
fiber optic delivery system for Triple Play Services (data, voice, IPTV/VoD)
with speeds of up to 2.488 Gbps downstream and 1.244 Gbps upstream.
The U Fiber network is intelligently managed using the included UNMS™
(Ubiquiti Network Management System) controller. U Fiber devices consist of
the U Fiber OLT (deployed at the provider premises) and the U Fiber Nano™G
consumer premises equipment ONUs.
GPON Optical Line Terminal
The U Fiber OLT offers eight GPON ports and supports up to 1024 concurrent
clients with physical links of up to 20 km in distance. Two SFP+ ports provide
10G of uplink connectivity.
The UF-OLT provides flexible power options, with two modular power adapter
bays that can house either AC/DC or DC/DC power modules. One AC/DC module is
included; additional modules can be purchased separately.
Features:
Ports: (8) GPON SFP Ports, (2) SFP+ Ports
Concurrent Clients: 1024 ONUs
GPON Range: Up to 20 km Link
GPON Speeds: 2.488 Gbps Upstream (TX), 1.244 Gbps Downstream (RX)
Wavelengths: 1490 nm Upstream (TX), 1310 nm Downstream (RX)
Max. Power Consumption: 40W
Mounting: 1U Rack-Mountable (Optional)
