Ubiquiti Networks U-POE-AF PoE adapter Gigabit Ethernet 48 V
KSh1,236.83
Delivers
up to 15W of PoE
Compatible with most UniFi Protect cameras and some APs such as U6+ and U6
Mesh
Surge, peak pulse, and overcurrent protection
Contains RJ45 data input, AC cable with earth ground, and PoE output
LED indicator for status monitoring
Ubiquiti U-POE-AF. Ethernet interface
type: Gigabit Ethernet, Ethernet LAN data rates: 1000 Mbit/s. Product color:
White. Power over Ethernet (PoE) voltage: 48 V, Input voltage: 100-240 V,
Input frequency: 50/60 Hz. Certification: CE, FCC, IC, UL. Width: 1.81″
(46 mm), Depth: 3.39″ (86 mm), Height: 1.3″ (33 mm)
Related products
-
Read moreReliable
Ubiquiti POE-24-12W-G
The Ubiquiti’s wide offer of products includes reliable and high quality
POE-24-12W-G adapters.The PoE Ubiquiti POE-24-12W-G is characterised by 90-260 V, 47-63 Hz input
voltage. It is compatible with airGateway series solutions.Construction
POE-24-12W-G is equipped with two Ethernet LAN (RJ-45) ports. It is
dedicated to powering 24 V to 0.5 A devices. It is equipped with a power
signal LED and a reset button.Use
The adapter can be used with CPE client stations and base stations. It can
be used at temperatures up to 40 degrees Celsius. The use of optional
mounting brackets allows it to be mounted on a wall.Key features
2 Ethernet LAN (RJ-45) ports
24 V PoE
90-260 V voltageComparison
POE-15-12W POE-24-12W POE-24-12W-G POE-24-24W POE-24-24W-G
OUTPUT VOLTAGE 15VDC @ 0.8A 24VDC @ 0.5A 24VDC @ 0.5A 24VDC @ 1.0A 24VDC @
1.0A
GIGABIT LAN Port NO NO YES NO YES
DIMENSIONS 85 x 44 x 29 mm 87 x 44 x 29 mm 87 x 44 x 29 mm 88 x 57 x 33
mm 88 x 57 x 33 mmManufacturer’s content
Read more in the manufacturer’s documentation
Specifications
-
Read moreUbiquiti
POE-24-24W-G – reliable work
The Ubiquiti POE-24-24W-G adapter is distinguished by its high quality and
reliability.POE-24-24W-G’s output power is 24 V with input voltage at a level of 1.0 A.
The adapter is equipped with two Ethernet LAN RJ-45 Gigabit ports.Reliability
This model boasts reliable operation and supports passive PoE. It is
compatible with Ubiquiti TOUGHCable grounding systems, which increases its
resistance in unfavourable outdoor conditions by protecting it from
electrostatic discharges. The device is compliant with industrial standards:
IEC 60950-1:2005+A1, UL60950-1, EN55022:2010 and EN55024:2010.Key features
2 Ethernet LAN ports (RJ-45)
maximum data transfer speed through Ethernet LAN 1000 Mbit/s
PoE 24 V
1 A input powerComparison
POE-15-12W POE-24-12W POE-24-12W-G POE-24-24W POE-24-24W-G
OUTPUT VOLTAGE 15VDC @ 0.8A 24VDC @ 0.5A 24VDC @ 0.5A 24VDC @ 1.0A 24VDC @
1.0A
GIGABIT LAN Port NO NO YES NO YES
DIMENSIONS 85 x 44 x 29 mm 87 x 44 x 29 mm 87 x 44 x 29 mm 88 x 57 x 33
mm 88 x 57 x 33 mmManufacturer’s content
Read more in the manufacturer’s documentation
Specifications
-
Read morePOE-48-24W
– Ubiquiti class quality
The PoE Ubiquiti POE-48-24W provides reliable protection from surges and
electrostatic discharges.Its input voltage is 90-260 V power, 47-63 Hz. The device supports PoE. It
has a 48 V output voltage and 0.5 power.Use
POE-48-24W can be used at temperatures ranging from -10 to 60 degrees
Celsius and stored at temperatures ranging from -20 to 85 degrees Celsius. It
can be used in relative humidity from 5 to 90%.Key features
48 V output voltage
0.5 A output power
230 VAC voltageComparison
POE-48-24W POE-48-24W-G POE-50-60W
OUTPUT VOLTAGE 48VDC @ 0.5A 48VDC @ 0.5A 50VDC @ 1.2A
GIGABIT LAN Port NO YES YES
DIMENSIONS 88 x 57 x 33 mm 96 x 62 x 35 mm 101 x 60 x 33 mmManufacturer’s content
Read more in the manufacturer’s documentation
-
Read moreUbiquiti
POE-50-60W – functionality and reliability
The Ubiquiti POE-50-60W adapter is a high quality device that complements
the Ubiquiti solutions.The POE-50-60W supports the passive Ethernet power solution. It is a
reliable device. In combination with the Ubiquiti TOUGHCable grounding system
it provides better protection from electrostatic discharges.Parameters
The device’s output voltage is 50 V with 1.2 A input power and 60 W power
consumption. The device is IEC 60950-1:2005+A1, UL60950-1, EN55022:2010 and
EN55024:2010 compliant.Construction
POE-50-60W is equipped with two Ethernet Gigabit RJ-45 ports. The
device is based on durable components which results in quality and
reliability as well as resistance to unfavourable weather
conditions.Key features
Gigabit interface
2 Ethernet LAN (RJ-45) ports
PoE 50 V
1.2 A input power
60 W power consumptionComparison
POE-48-24W POE-48-24W-G POE-50-60W
OUTPUT VOLTAGE 48VDC @ 0.5A 48VDC @ 0.5A 50VDC @ 1.2A
GIGABIT LAN Port NO YES YES
DIMENSIONS 88 x 57 x 33 mm 96 x 62 x 35 mm 101 x 60 x 33 mmManufacturer’s content
Read more in the manufacturer’s documentation
Specifications
-
Read moreUbiquiti
POE-48-24W-G – comfortable power
The Ubiquiti POE-48-24W-G is a uniquely reliable adapter that supports
passive type powering through the Ethernet network.The device is compatible with Ubiquiti TOUGHCable grounding systems which
provide increased protection from electrostatic discharges. The device’s
output voltage is 48 V with input power of 0.5 A.Construction
POE-48-24W-G is equipped with two Ethernet LAN Gigabit RJ-45 ports.
The adapter is IEC 60950-1:2005+A1, UL60950â€1, EN55022:2010, EN55024:2010
and FCC Class B compliant.Key features
2 Ethernet LAN (RJ-45) ports
PoE 48 V
90-260 input voltage
47-63 Hz input dataComparison
POE-48-24W POE-48-24W-G POE-50-60W
OUTPUT VOLTAGE 48VDC @ 0.5A 48VDC @ 0.5A 50VDC @ 1.2A
GIGABIT LAN Port NO YES YES
DIMENSIONS 88 x 57 x 33 mm 96 x 62 x 35 mm 101 x 60 x 33 mmManufacturer’s content
Read more in the manufacturer’s documentation
Specifications
