Wizord 2i Electric Fence Energiser
KSh20,000.00
Description
Wizord 2i Electric Fence Energiser
Enclosure size
285(L) x 212(W) x 120(D)mm
Weight
3.1kg excluding battery (7AH)
5.3kg including battery (7AH)
IP rating
IPx4
Operating temperature
-10°C to 50°C
Operating humidity
< 80% non-condensing Electrical supply voltage 240V Typical power consumption 17VA (normal operating conditions) Standby Time 24hrs (fully charged battery) Energy output 2.0 Joule (500 Ohms load) Open circuit voltage 7400V
Related products
-
Electric fence digital voltmeter – Kenya
KSh18,000.00Add to cartElectric fence digital voltmeter
Electric fence digital voltmeter Quickly and easily obtains a digital reading of your fence voltage with the Gallagher Fence Volt Meter. Monitors fence voltage and helps trace shorts in the fence line. Electric fence digital voltmeter helps detect a short in your electric fence that occurs when the power escapes to the ground.
This can be caused by a broken underground cable, broken wire or insulator, a loose connection, or something touching the fence, such excessive vegetation. Digital Voltmeter can help you locate the source of a short by measuring the voltage in the fence line. You can also use the Neon Fence Tester, although it is not as accurate.
How to use Electric fence digital voltmeter
Attach it to the fence line, moving it laterally to get a good contact, and place the probe in the ground. You will see a reading on the screen – on a good electric fence line this should be in excess of 6,000 volts.
If the voltage is just slightly below normal – say 5,000 volts – then you probably have a small fault caused by light vegetation, for instance. However, if the reading is substantially lower, then a major fault exists.
To find this fault, move along the fence line, taking readings every 100 metres or so. As a rule of thumb, the voltage will drop roughly 100 volts every 100 metres as you head in the direction of the fault, and will then level out once you pass the fault.
If the fault is not obvious, you should systematically isolate areas of your electic fence using cut-out switches. Once you have located the problem area, you may have to isolate individual wires to pinpoint the problem.
Electric fence digital voltmeter
Electric fence digital voltmeter specifications
Part Number MLD-003
Item Weight 3 ounces
Product Dimensions 7.01 x 1.3 x 2.76 inches
Item model number MLD-003
Is Discontinued By Manufacturer No
Size 17.8*7.0*3.3cm
Color Black
Material ABS
Shape Rectangle
Power Source Battery-powered
Voltage 9900 volts
Handle Material Plastic
Display Style LCD
Batteries Included** No
Batteries Required** No
Pile 9V.6F22or equivalent -
Add to cartDescription
Merlin 4i Electric Fence Energizer With keypad 4 JouleMerlin 4i Electric Fence Energizer With keypad 4 Joule a keypad for controlling and programming the energizer. The energizer can be installed near the fence and the keypad can be located where it is most convenient for the user. This allows the user to control the energizer remotely, with up to four keypads (EE-MKP).
Merlin 4i Electric Fence Energizer With keypad 4 Joule Specifications
Enclosure size: L285 x W212 x D120Weight excluding battery (7AH): 3.1kgWeight including battery (7AH): 5.3kgIP rating: IPx4Operating temperatures: -10°C to 50°COperating humidity: < 80% non-condensingElectrical supply voltage: 240VTypical power consumption (normal operating conditions): 18VAStandby time (fully charged battery): 24hrsEnergy output 500 Ohms load: 3.7 JouleOpen circuit voltage: 8 000V Stock Code Name Description E-MER4I Merlin 4i with keypad Merlin 4i – 4J Energizer with Keypad E-MER4I/UK Merlin 4i with keypad Merlin 4i – 4J Energizer with Keypad – UK Plug
-
Stafix AM1 Alarm Monitor
KSh23,000.00Add to cartDescription
Stafix AM1 Alarm MonitorStafix AM1 Alarm Monitor from Mtech Networks Nairobi, At Mtech we have all-electric fencing solutions you may require to safeguard your property.
Stafix AM1 Alarm Monitor unit pulses and operates like a normal electric fence energizer, except that the voltages are under 50 V, making it intrinsically safe and below any perceived dangerous high voltages.
Stafix AM1 Alarm Monitor has been a huge success as installers faced with sites under the new SANS electric fencing act, that were deemed dangerous as high voltage wires were exposed to public access areas, now have a solution.
Stafix AM1 Alarm Monitor installers were previously faced with either removing the fence or installing an expensive barrier fence. With the ZLM monitors, fence sections below 1.5 m could be wired into the JVA monitor and still be fully monitored and alarmed without any dangerous shocks.
Stafix AM1 Alarm Monitor has been very successful with many housing estates, industrial companies and old age homes. Even some government organizations have replaced certain energizers in their systems with JVA ZLM units to achieve their COC compliance.
Stafix AM1 Alarm Monitor TCP/IP interface and networkability, the ZLM4 is able to slot into any already networked perimeter patrol system.
Stafix AM1 Alarm Monitor specifications
Create multiple zones/sectors
Dynamic fence voltage monitoring
LED displays fence status
Relays for siren/strobe
Adjustable fence voltage delay and trip settings
12 V battery powered. -
Add to cartDruid 15 LCD Electric Fence Energizer 5 Joule
Druid 15 LCD Electric Fence Energizer 5 Joule LCD display in the Druid range makes information on the status and performance of the energizer quick and easy to read. Druid 15 LCD Electric Fence Energizer Using the Adaptive Power Technology (APT) pioneered by Nemtek, these energizers offer a unique technology to detect how much power a fence can accept and handle before it starts to arc and waste energy.
Druid 15 LCD Electric Fence Energizer maximizes the power on the fence and minimises false alarms. Druid 18LCD The LCD display in the Druid range makes information on the status and performance of the energizer quick and easy to read. Using the Adaptive Power Technology (APT) pioneered by Nemtek. Druid 15 LCD Electric Fence Energizer offers a unique technology to detect how much power a fence can accept and handle before it starts to arc and waste energy. This maximizes the power on the fence and minimizes false alarms.
Druid 18LCD energizer offers the following:7.6J output deal choice for long-distance series electric fencing systems that require monitoringBuilt-in alarm monitors tampering or faults on the high voltage and earth.
Druid 15 LCD Electric Fence Energizer fence wire connectable to armed response radio or GSM module lighting and power surge protectionIntelligent power saving to extend battery life easy-to-use tag included for controlling the energized walk test mode for easy fence testing the LCD background colour changes to easily identify the fence condition.
Druid 15 LCD Electric Fence Energizer powered by 230V mains and includes a built-in battery for back up powerBuilt-in gate alarm inputs to monitor if the gate is open or closed Optional keypad for controlling and programming the energizer. This allows the user to control the energizer remotely, with up to two keypads
15 LCD Electric Fence Energizer 5 Joule specifications
• 4.6 Joule output energy (single zone)
• Robust and flexible design for home and commercial security
• Built-in alarm monitors tampering or faults on the high voltage and earth fence wires
• Connectable to armed response radio or GSM module
• Lightning and power surge protection
• Intelligent power saving to extend battery life
• Easy-to-use tag included for controlling the energizer
• Walk test mode for easy fence testing,• The LCD background colour changes to easily identify the fence condition
• Powered by 240V mains and includes built-in battery for back-up power
• Built-in gate alarm input to monitor if the gate is open or closed
• Optional keypad for controlling and programming the energizer. This allows the user to control the energizer remotely, with up to two keypadsSpecifications
Enclosure size: L285 x W212 x D120
Weight excluding battery (7AH): 3.1kg
Weight including battery (7AH): 5.3kg
IP rating: IPx4
Operating temperatures: -10°C to 50°C
Operating humidity: < 80% non-condensing Electrical supply voltage: 240V Typical power consumption (normal operating conditions): 18VA Standby time (fully charged battery): 24hrs Energy output 500 Ohms load: 4.6 Joule Open circuit voltage: 9 000V -
1.5mm twin earth electrical cable – Kenya
KSh17,000.00Add to cart1.5mm twin earth electrical cable
1.5mm twin earth electrical cable is a PVC**insulated sheathed brown and earth cable that**is**suitable**for a**general purpose wiring when an earth continuity conductor is required. The cable size is 1.5mm. Available in pre-cut lengths and also on 100m reels so it can be cut to desired length.
1.5mm twin earth electrical cable Specification
Voltage**450/750V Cross-sectional Area :1.5 mm Conductor**Plain annealed copper Insulation****PVC (Polyvinyl Chloride) Sheath:**PVC (Polyvinyl Chloride) Temperature Rating:**-15**C to +70**C Packaging**Iron or Wooden Drum Application:**Used as wire for household appliance, mechanic equipment installation and dynamic light, etc.
Colour Grey
Size 1.5mm x 100m
Length 100m Reel
Weight 8.68Kg
Brand Builder Depot
Barcode 5060146770682
EDP code 1.5TE
Pack Full Drum
Cores 2 Core + Earth
**
1.5mm twin earth electrical cable
twin earth 1.5mm** electrical cable
Twin and Earth Flat Electric Wiring Power Cable
**
