Name: Wood coil 250m coaxial cable CXT-1 Eca/A 19VAtC.A White Televes | +254720548999
SKU: TELEVES-212801
Price: 38116.00 KES
Availability: InStock

Coaxial cable with live made of copper steel and aluminum mesh (CCS / Al), with excellent braiding coverage (77%). A 19VAtC.A cable, double shielding and PVC cover.

Stands out for
Internal conductor made of copper-plated steel and aluminum mesh
Class A shielding
Euroclass Eca
Features
Outer PVC cover in?White
Characteristic impedance of 75 ohm
250m wood coil.?

Double-shielded Class A coaxial cable

With 2 shielding layers, these cables provide an outstanding shielding thanks to a high-coverage braid.?

They belong in EN 50117 standard Class A, according to their structural properties:

For 5 MHz – 30 MHz => TI < 5 m?/m For 5 MHz - 1000 MHz => SA > 85 dB
For 1000 MHz – 2000 MHz => SA > 75 dB
For 2000 MHz – 3000 MHz => SA > 65 dB

Where the transfer impedance (TI) defines how effective the shielding is at low frequencies, while the shielding attenuation (SA) defines it in the 30 MHz-to-3000 MHz range.

Specifications
Model ? 212801
Type CXT-1
Standard EN 50117-2-4
EuroClase Eca
Class A
Central conductor ? mm 1
Material Cu
Res. Ohm/Km <23 Dielectric ? mm 4.5 Material PEE Inner sheet Aluminum + Polyester Mesh Material Al Dimensions?(Ncx Nsx ?) 16 x 8 x 0.12 Res. Ohm/Km <31 % coverage 79 Anti-immigrant poster No Petro-Gel No Outside coverage ? mm 6.5 Material PVC Minimum bend radius mm 32.5 Shield at 1GHz dB >85
Capacity pF/m 54
Impedance Ohm 75
Transfer Impedance (5-30MHz) mOhm/m ?5
Propagation speed min. % 82
Attenuations (dB / m)
Frequency (MHz)
5 0.01
47 0.04
90 0.05
200 0.09
500 0.14
800 0.19
1000 0.21
1350 0.25
1750 0.29
2050 0.32
2300 0.35
