24 Port 1U SC/UPC Duplex MM Adapter Rack mount ODF – Kenya

Related products

•

  20km Transceiver 1000 Base-LX SPF Mini GBC Module – Kenya

  KSh30,000.00

  20km Transceiver 1000 Base-LX SPF Mini GBC Module

  The 20km Transceiver 1000Base-LX SFP Mini GBIC Module is a high-performance optical transceiver designed for long-distance Gigabit Ethernet connectivity. It supports data rates up to 1 Gbps and operates over singlemode fiber with a maximum reach of 20 kilometers.

  Featuring a 1310 nm wavelength, this module is equipped with LC duplex connectors and provides reliable, high-speed data transmission with a link budget of 11 dB and a typical receiver sensitivity of -20 dBm. It operates within a temperature range of 0°C to +70°C and is compliant with IEEE 802.3z standards.

  The module is hot-swappable, allowing for easy replacement without powering down, and includes built-in digital diagnostic monitoring (DDM) for real-time performance tracking. It adheres to safety and environmental standards, including RoHS compliance, making it a versatile and dependable solution for high-speed networking applications.

  Technical Details
  MANUFACTURER H!Fiber.com
  PART NUMBER ASF13-24-10-D-Net(2pcs)
  ITEM WEIGHT 2.22 ounces
  PACKAGE DIMENSIONS 6.69 x 4.92 x 0.75 inches
  ITEM MODEL NUMBER ASF13-24-10-D-Net(2pcs)
  IS DISCONTINUED BY MANUFACTURER No
  SIZE 1000Base-LX: 10km
  COLOR For Netgear
  ITEM PACKAGE QUANTITY 1
  BATTERIES INCLUDED** No
  BATTERIES REQUIRED** No
  Compatible for Netgear AGM732F and other open equipments with 1G SFP port. 2-Pack
  1000Base-LX Gigabit Ethernet, 1.25 Gbps, 1310nm wavelength ,10km reach, Singlemode,Dual LC connector.
  Hot-Pluggable SFP Transceiver Module, PLUG and PLAY, with Advanced DDM Function to monitor real-time parameter and state on fiber links.
  100% Each transceiver is individually done performance test and compatibility test in our Test center before packing.
  Enjoy 30-day free-returned and 3-year warranty service

  Add to cart

  Quick View
•

  1 X 16 PVC 0.9mm fiber jacket SC/PC Rack Splitter connectors – Kenya

  KSh28,000.00

  1 X 16 PVC 0.9mm fiber jacket SC/PC Rack Splitter connectors

  The 1 x 16 PVC 0.9mm Fiber Jacket SC/PC Rack Mount Splitter is an efficient optical splitter designed for distributing a single input signal to 16 output fibers. Ideal for use in high-density environments, this splitter features a compact 19-inch rack-mountable design, ensuring space optimization in network setups.

  Equipped with SC/PC connectors, it provides reliable signal transmission with minimal insertion loss and reduced back reflection. The splitter supports a broad wavelength range of 1260 nm to 1650 nm, offering flexibility for various network applications. With a typical insertion loss of **14.5 dB and a high return loss of **50 dB, it ensures consistent signal quality and performance.

  The device utilizes 0.9mm PVC-jacketed fibers, providing durability and flexibility for easy installation and maintenance. It is compliant with industry standards such as Telcordia GR-1209, GR-1221, and RoHS, guaranteeing high reliability and safety.

  Designed for ease of use, it includes built-in cable management and clear port labeling, making it a practical solution for FTTH, PON, and CATV networks. The splitter offers robust performance and long-term reliability, making it an essential component for efficient optical signal distribution.

  **

  Add to cart

  Quick View
•

  12 Core Multi Mode Fiber Optic Cable – Kenya

  KSh150.00

  12 Core Multi Mode Fiber Optic Cable**

  12 Core Multi-Mode Fiber Optic Cable duct grade unitube cable range has been designed to be lightweight and compact.

  The 4-12 fibre product variants are constructed around a 2.90mm gel filled loose tube, whereas the 16-24 fibre variants use a 4.00mm loose tube.

  12 Core Multi-Mode Fiber Optic Cable** is designed to accommodate environments where the installation of the fibre optic cable might be strenuous. 12 Core Multi-Mode Fiber Optic Cable are positioned in a loose tube manufactured with a modulus plastic.

  12 Core Multi-Mode Fiber Optic Cable tubes are filled with a water-resistant filling compound and has a fibre re-enforcement (FRP) located in the centre of the cable as a non-metallic strength member. 12 Core Multi-Mode Fiber Optic Cable Protected by a Polyethylene sheath, Heavy Duty Duct cable is the ultimate in reliability for riser shafts and or extensions to other buildings.

  Multi Mode Fiber Optic Cable Applications:** Internal cable for installation in trunking, under floor or ceiling spaces**

  ** Short run external links between buildings**

  ** Fibre backbones in riser and horizontal configurations

  12 Core Multi Mode Fiber Optic Cable specification

  Compact water blocked design ** 12 fibres ** Level 1 rodent protection ** Universal sheath ** External grade sheath cables also available (UDE)

  QUICKTAG 53-TB12-BK
  MANUFACTURER MCL
  FIBRE COUNT 12
  BUILD TYPE Tight Buffered
  PROTECTION Flame Retardant
  MODE Multimode 50** OM3
  ENVIRONMENT TYPE Universal
  Loose-tube: 4-24 core Cable
  **Fibre Cores 4 8 12 16 24
  **Weight kg/km 25 34 41 47 62
  **Outer Diameter mm 5 5.9 6.5 7.2 8.3
  **Tensile Strength (during installation) N 640 920 1100 1430 1430
  **Bend Radius mm 80 95 100 113 128
  **Crush Resistance N 2000
  **Operating Temperature Range **C 15 ** +60
  12-Core Indoor Multimode Fiber Optic Cable
  Optic Fibre Cables
  Optic Fibre Cables Price
  Buy Optic Fibre Cables
  Multimode 12-Core** Fiber Optic Cable

  **

  Add to cart

  Quick View
•

  1 X 8 PVC 0.9mm fiber jacket SC/PC Rack Splitter connectors – Kenya

  KSh7,500.00

  1 X 8 PVC 0.9mm fiber jacket SC/PC Rack Splitter connectors**

  1 X 8 PVC 0.9mm fiber jacket SC/PC Rack Splitter connectors from the leading fiber dealer in Nairobi kenya, buy online 1 X 8 PVC 0.9mm fiber jacket SC/PC Rack Splitter connectors and have it delivered.

  PLC splitter is a type of optical power management device that is fabricated using silica optical waveguide technology to distribute optical signals from Central Office (CO) to multiple premise locations.
  **
  Blockless PLC splitter has stronger fiber protection than bare fiber splitter, which is a miniaturization result of cassette splitter. It**s mainly used for various connection and distribution boxes or network cabinets.
  **
  Product Specification
  **
  Package Style Mini Module Configuration Type 1**8
  Fiber Type Singlemode G.657A1 Connector Type SC/APC
  Input/Output Fiber Diameter 900**m Input/Output Fiber Length 1.5m
  Insertion Loss **10.6dB Return Loss **50dB
  Loss Uniformity **0.8dB Directivity **55dB
  Polarization Dependent Loss **0.2dB Temperature Dependent Loss **0.5dB
  Wavelength Dependent Loss **0.3dB Operating Bandwidth 1260~1650nm
  Split Ratio 50/50 Steel Tube Dimensions (HxWxD) 0.16**x2.36**x0.28** (4x60x7mm)
  Operating Temperature -20~70**C Storage Temperature -40~85**C

  Add to cart

  Quick View
•

  1X64 blockless 900µm fiber LC/PC PLC Fiber splitter connectors – Kenya

  KSh20,000.00

  1X64 blockless 900µm fiber LC/PC PLC Fiber splitter connectors

  The 1×64 Blockless 900µm Fiber LC/PC PLC Fiber Splitter is a high-performance optical splitter designed for distributing a single input signal to 64 output fibers. Featuring a compact, blockless design, this splitter is ideal for space-constrained installations and provides efficient signal distribution in fiber optic networks.

  It uses LC/PC connectors with a physical contact polish to ensure minimal insertion loss and back reflection. The splitter supports a wide wavelength range of 1260 nm to 1650 nm and offers a typical insertion loss of **20.5 dB, with high return loss of **50 dB and uniformity of **2.0 dB.

  The device is equipped with 900µm tight-buffered fibers, providing enhanced flexibility and durability. Designed to meet industry standards such as Telcordia GR-1209, GR-1221, and RoHS, it ensures reliable and consistent performance across various network applications including FTTH, PON, and CATV. The splitter is easy to install and maintain, making it a practical solution for high-density fiber optic deployments.

  Product Name: Fiber Optic PLC Splitter 1×16 Blockless With LC APC 9 / 125**m Connector Configuration Type: 1×16
  Package Style: Mini Module Connector Type: LC/APC
  Fiber Type: Singlemode Return Loss: **60dB
  Operating/Storage Temperature: -40~85°C Directivity: **55dB
  High Light:
  rack mount plc splitter

  ,

  plc splitter module



  Add to cart

  Quick View
