24 Port 1U SC/UPC Duplex SM Adapter Rack mount ODF – Kenya
KSh19,000.00
24 Port 1U SC/UPC Duplex SM Adapter Rack mount ODF
24 Port 1U SC/UPC Duplex SM Adapter Rack mount ODF from the leading fiber dealer in Nairobi Kenya, buy online 24 Port 1U SC/UPC Duplex SM Adapter Rack mount ODF and have it delivered at your doorstep.
Specifications
Type Dimension (mm) Max capacity (core) Carton size(mm) Qty/ carton (pc) G.W (kg)
GPRF-1U-SC24 430*300*1U 24 485*420*350 5 25
GPRF-1U-FC24 430*300*1U 24
GPRF-1U-2SC12 430*300*1U 24
GPRF-1U-2SC24 430*300*1U 48
Note: The body is made of cold rolled steel sheet FC,ST,SC,LC adapter available Technical parameters
parameters value
Dimension(length * width * height) 430*300*44.5mm
Weight 4kgs
Fiber radius of curvature **40mm
The additional loss fiber without additional loss in the holding tray
The fiber length in the tray 1.6m
The fiber maximum capacity SC/FC 48 cores, LC up to 96 cores
The applicable temperature range -40****+60**
The lateral pressure 500N
Anti-shock: 750N
Packing list: * terminal box body: 1 sets * mounting ears: 1 sets * adapter mounting screws:96pcs * welding mark: 4 sets * optical fiber protection tube: 2 ~ 48pcs * cable tie: 4 ~ 16pcs
24 Port 1U SC/UPC Duplex SM Adapter Rack mount ODF
24 Port 1U SC/UPC Duplex SM Adapter Rack mount ODF from the leading fiber dealer in Nairobi Kenya, buy online 24 Port 1U SC/UPC Duplex SM Adapter Rack mount ODF and have it delivered at your doorstep.
Specifications
Type Dimension (mm) Max capacity (core) Carton size(mm) Qty/ carton (pc) G.W (kg)
GPRF-1U-SC24 430*300*1U 24 485*420*350 5 25
GPRF-1U-FC24 430*300*1U 24
GPRF-1U-2SC12 430*300*1U 24
GPRF-1U-2SC24 430*300*1U 48
Note: The body is made of cold rolled steel sheet FC,ST,SC,LC adapter available Technical parameters
parameters value
Dimension(length * width * height) 430*300*44.5mm
Weight 4kgs
Fiber radius of curvature ?40mm
The additional loss fiber without additional loss in the holding tray
The fiber length in the tray 1.6m
The fiber maximum capacity SC/FC 48 cores, LC up to 96 cores
The applicable temperature range -40??+60?
The lateral pressure 500N
Anti-shock: 750N
Packing list: * terminal box body: 1 sets * mounting ears: 1 sets * adapter mounting screws:96pcs * welding mark: 4 sets * optical fiber protection tube: 2 ~ 48pcs * cable tie: 4 ~ 16pcs
