Cardboard coil 100m Coaxial Cable CXT LSFH Dca 18RtC ?…
KSh18,876.00
Cardboard coil 100m. Coaxial cable with live made of copper and copper-plated aluminum mesh (Cu/CCA), double shielded. An 18RtC cable, with an LSFH sheath. White
Cardboard spool 100m. Live coaxial cable made of copper and copper-plated aluminum mesh (Cu/CCA), double-shielded. One 18RtC cable, with LSFH sheath.
Stands out for
Internal conductor made of copper and copper-plated aluminum mesh
Euroclass Dca-s2, d2, a2
Main Features
LSFH exterior cover in?white
75 ohm characteristic impedance
Available on reels of different footage
Specifications
Guy CXT
Standard EN 50117-2-4
Euroclass Dca
Euroclass: Emission of opaque fumes s2
Euroclass: Falling Flammable Particles d2
Euroclass: Acidity a2
Class B
Central Conductor Diameter mm one
Central Conductor Material Copper (Cu)
Central conductor resistance ? / km <23
Dielectric Diameter mm 4.8
Dielectric Material Expanded Polyethylene (PEE)
Dielectric Color White RAL 9003
Inner foil Copper + Polyester
Mesh Material Aluminum + Copper
Mesh dimensions: number of yarns groups (Nc) 16
Mesh Dimensions: number of threads per group (Ns) 3
Mesh dimensions: wire diameter (?) mm 0.12
Mesh resistance ? / km <35
Mesh coverage % 35
2nd shielding sheet No
2nd shielding sheet glued to the dielectric No
Petro-Gel No
Anti-migration sheet No
Outer cover diameter mm 6.6
Material Outer cover LSFH
Thickness Outer Cover mm 0.3
Minimum bend radius mm 33
Transfer impedance (5-30MHz) m? / m <50
1GHz shielding dB > 75
Spark Test Vac 3000
Capacity pF / m 55
Impedance ? 75
Propagation velocity min. % 82
Operating temperature ? C -25 … 70
Frequencies
5 MHz 47 MHz 54 MHz 90 MHz 200 MHz 500 MHz 698 MHz 800 MHz 862 MHz 950 MHz 1000 MHz 1220 MHz 1350 MHz 1750 MHz 2050 MHz 2150 MHz 2200 MHz 2300 MHz 2400 MHz 3000 MHz
Attenuation (typ.) dB / m
0.01 0.05 0.05 0.06 0.09 0.14 0.16 0.18 0.19 0.19 0.2 0.22 0.24 0.28 0.3 0.31 0.3 0.31 0.33 0.36
