Coaxial cable in black color Cu, Cu CLASS A in 100m coil
Coil of 100 meters of coaxial cable T-100 for exterior in black color
Televes cable 215501 is copper with black PEE cover, perfect for our outdoor installation.
This coaxial cable has an inner conductor made of copper 1.13 mm thick, a dielectric of 4.8 mm, a copper mesh cover and a black PEE outer cover.
The image may not correspond with the item.
Televes 215501 cable offers fabulous features at a very affordable price.
What technical features does the 215501 cable have?
Inner Conductor – Mesh Composition Copper-Copper?
?Model Telev?s T-100
Inner conductor ?? mm 1.13
?Material? ?Copper
?Resistance ohm/Km 20
?Dielectric ?? mm 4.8
?Material? Expanded polyethylene
Screen Shield ?Material? Copper + Polyester
?Net ?Resistance ohm/Km <20
?Material? Copper
Antimigratory film yes
Sealing gel no
External cover ?? mm 6.6
?Color? Black
?Material? PEE
Minimum bend radius mm 33
?Shielding dB >75
?Capacity pF/m 55
Type of USE Exterior
?Packaging ?meters m 100
?Attenuations
?Frequency ?200 MHz 0.08
?500 0.12
?800 0.15
?1000 0.18
?1350 0.21
?1750 0.24
?2050 0.27
?2150 0.27
?2300 0.28
