DIN Rail Adapter Easy F Series Distributors/Diverters for Televes
DIN Rail Adapter for Televes Easy F Series Distributors/Diverters
This is an adapter to install Easy F series diverters or distributors on the DIN rail. The adapter is fixed to the DIN rail using screws, which are included.
The fixation on the rail is very robust since it is done with screws to the two adapters. This way we ensure that there is no accidental uncoupling.
The EasyF series is a form of connection for the internal conductor of the coaxial cable, which is inserted directly into the device to increase the reliability of the connection itself, without using F connectors. The connection is made through a single screw.
**
Technical Specifications of the DIN Rail Adapter for EasyF Series Distributors/Diverters
Brand: Televes
Reference: 549901
EAN: 8424450300459
Gray
Accessories: Includes Screws
Plastic material
Series: Easy F
