Ethernet Adapter – Televes 2 fibers 769210 from Televes
Ethernet Adapter – SFP for Coaxdata
The Televes 769210 adapter is a media adapter that connects to the Ethernet input of a CoaxData device so that it has access to an Ethernet signal via fiber optics.
This adapter has a maximum transmission speed of 1250 Mbps.
The Televes Ethernet can transmit the internet signal at a maximum distance of 10 kilometers.
The Televes 769210 adapter connects to the Ethernet input of a CoaxData device so that it has access to an ethernet signal via fiber optics.
What technical characteristics does the 769210 adapter have?
Operating values Units Min. Typ. Max.
Maximum voltage supply V 3.13 – 3.46
Operating temperature ? C -20 – +60
Data rate Mbps – – 1250
Max distance Km – – 10
Optical transmitter Units Min. Typ. Max.
Value of Wavelength nm 1260 1310 1360
Bandwidth nm – – 4
Differential input voltage mV 500 – 2400
Optical output power dBm -9 -5 -3
Up / down time ps – – 260
Voltage TX Disable V 2.0 – Vcc
Voltage TX Fault V 2.0 – Vcc
Optical receiver Min. Units. Typ. Max.
Differential output voltage mV 400 – 1600
Optical sensitivity of the dBm receiver – -19
Maximum input optical power dBm -3 – –
Voltage of “loss of signal” V 2 – –
Signal detection range dBm -35 – -20
Signal detection hysteresis dB 0.5 – 6
