For saddle&clamp DC blocked
75 Ohm Televes DC blocking (for Easy F connections). Ref 4087 Televes.
This DC blocked Vdc.**
This type of load of 75 Ohm for flange type connection, comptible with referring and distributors connector “Easy F” Televes. It includes a DC blocking condenser feed stream.
It can also be used in other elements from other manufacturers using similar connections, as Fagor. Make sure that the center conductor conexiona properly enabled female opening just outside the load conexiona chassis dealer or distributor.
You can also install amplifiers “Minikom” Televes with “Easy F” connections.
Related products
-
Read moreTELEVES Nevoswitch 9×32
CASCADE-TERMINATED 9 In 32 Out c/w
Output Earth Bar Only 2 Year Warranty *Special Order! NCNR – Check Lead
Time* Multiswitch equipped with 9
inputs (one terrestrial and 8 for two satellites, each with its four
polarities) and 32 user outputs. Can be used as a terminal (star topology) or
as a cascade by using a simple switch.
Main Features: 10 dB Low Gain
(LG) / High Gain (HG) switch for the attenuation of the satellite input
signal for each 8-user group Remote power feeding using VL Current
circulation between all inputs and cascades Compatible with return-channel
applications European design, quality, and manufacturing Very compact Made of
zamak Input and output colour identification Available ECO mode Selector
switch to shift between cascade and terminal modes 12 V power supply Low
power consumption -
Read moreTELEVES Nevoswitch 9×9 CASCADE Launch
Amp 21dB SAT 17dB Terr – 2 Year
Warranty *Special Order! NCNR – Check Lead Time* NevoSwitch amplifier equipped with 9 inputs
(one terrestrial and the four polarities of two satellites) that allows
increasing the number of users in the installation while optimizing the
signal received by each of them. Around 27dB and 31dB amplification in
terrestrial and satellite respectively. Compatible with the return path
(passive). Main Features: High output level Switch for the selection
of whether or not to power the terrestrial pre-amplifiers (VDC or OFF) Gain
(20 dB) and slope (12 dB) individual adjustment Power feeding through the VL
input/output Very compact Made of zamak Input and output colour
identification 12 V power supply Low power consumption -
Read moreTELEVES 13x13x12 CASCADE Multiswitch 13 In 12 Out c/w Output Earth Bar Only 2
Year Warranty *Special Order! NCNR – Check Lead Time* This unit can be used as a cascade element
since it has 13 outputs to connect to other switches and increase the number
of users. This range of products has been designed with the ECO system: as
the number of users decreases, the power consumption of the system will
decrease as well. Gain in the FI band can be selected individually for each
group of 8 users to provide a balanced output. -
Read moreTELEVES Euroswitch 17x17x8 CASCADE 17 In 8 Out – 2 Year Warranty *Special
Order! NCNR – Check Lead Time* Compact
multiswitch equipped with 17 inputs (one terrestrial and 16 for four
satellites, each with its four polarities) and 8 user outputs. Thanks to its great compactness and its
optimized electronic design, it presents very low through and tap losses.
This allows to reduce the number of amplifiers needed in the cascade and to
obtain a better balanced signal in the users, even in large collective
installations. Can be used as a
terminal (star topology) or as a cascade by using a simple switch. In
addition, it incorporates a second switch that actives the TForce technology,
which automatically adjusts the terrestrial signal and keep it constant
despite variations in the reception. RED compliant Main Features: High shielding (A class) thanks to its
manufacture in Zamak Versatile: selector switch to shift between cascade and
terminal modes Low consumption under normal conditions. In addition, ECO mode
reduces consumption as the number of connected users decreases Wide 12-18V
power supply range, making it compatible with most existing systems Current
circulation between all inputs and cascades Input and output colour
identification -
Read moreTELEVES Euroswitch 9x9x8 CASCADE 9 In 8 Out c/w Output Earth Bar Only 2 Year
Warranty *Special Order! NCNR – Check Lead Time* Compact multiswitch equipped with 9 inputs
(one terrestrial and 8 for two satellites, each with its four polarities) and
8 user outputs. Thanks to its great
compactness and its optimized electronic design, it presents very low through
and tap losses. This allows to reduce the number of amplifiers needed in the
cascade and to obtain a better balanced signal in the users, even in large
collective installations. Can be used
as a terminal (star topology) or as a cascade by using a simple switch. In
addition, it incorporates a second switch that actives the TForce technology,
which automatically adjusts the terrestrial signal and keep it constant
despite variations in the reception. RED compliant. Main Features: High shielding (A class) thanks to its
manufacture in Zamak Versatile: selector switch to shift between cascade and
terminal modes Low consumption under normal conditions. In addition, ECO mode
reduces consumption as the number of connected users decreases Wide 12-18V
power supply range, making it compatible with most existing systems Current
circulation between all inputs and cascades Input and output colour
identification
