Ikusi BAS-915 Base to connect 5 single-channel units SZB
KSh4,044.00
IKUSI BAS-915. Base plate with power connecting bar. Capacity: 1 power supply+4 RF modules SZB; or 5 RF modules
Features
Support base with power bar. Capacity: 1 feeder + 4 RF modules; or 5 RF modules.
