Jva Z18 Electric Fence Energiser
KSh40,000.00
Fiber
Description
Jva Z18 Electric Fence Energiser
The JVA Z18 is a single zone security electric fence energiser purpose built for control and monitoring of perimeter security electric fences. It can meet all of the requirements from basic residential to fully integrated high profile installations.
The Z18 can be programmed and controlled using the optional LCD keypad or Touch keypad. It can also be networked with other Z Range energisers to form a pulse synchronized group for larger sites which require multiple zones.
The Z18 allows you to control and supervise an electric fence from:
• On Site using the optional LCD keypad or Touch keypad
• A control room using Perimeter Patrol1 PC Software
Related products
-
Electric fence digital voltmeter – Kenya
KSh18,000.00Add to cartElectric fence digital voltmeter
Electric fence digital voltmeter Quickly and easily obtains a digital reading of your fence voltage with the Gallagher Fence Volt Meter. Monitors fence voltage and helps trace shorts in the fence line. Electric fence digital voltmeter helps detect a short in your electric fence that occurs when the power escapes to the ground.
This can be caused by a broken underground cable, broken wire or insulator, a loose connection, or something touching the fence, such excessive vegetation. Digital Voltmeter can help you locate the source of a short by measuring the voltage in the fence line. You can also use the Neon Fence Tester, although it is not as accurate.
How to use Electric fence digital voltmeter
Attach it to the fence line, moving it laterally to get a good contact, and place the probe in the ground. You will see a reading on the screen – on a good electric fence line this should be in excess of 6,000 volts.
If the voltage is just slightly below normal – say 5,000 volts – then you probably have a small fault caused by light vegetation, for instance. However, if the reading is substantially lower, then a major fault exists.
To find this fault, move along the fence line, taking readings every 100 metres or so. As a rule of thumb, the voltage will drop roughly 100 volts every 100 metres as you head in the direction of the fault, and will then level out once you pass the fault.
If the fault is not obvious, you should systematically isolate areas of your electic fence using cut-out switches. Once you have located the problem area, you may have to isolate individual wires to pinpoint the problem.
Electric fence digital voltmeter
Electric fence digital voltmeter specifications
Part Number MLD-003
Item Weight 3 ounces
Product Dimensions 7.01 x 1.3 x 2.76 inches
Item model number MLD-003
Is Discontinued By Manufacturer No
Size 17.8*7.0*3.3cm
Color Black
Material ABS
Shape Rectangle
Power Source Battery-powered
Voltage 9900 volts
Handle Material Plastic
Display Style LCD
Batteries Included** No
Batteries Required** No
Pile 9V.6F22or equivalent -
Stafix 4600w Electric Fence Energiser
KSh180,000.00Add to cartDescription
Stafix 4600w Electric Fence EnergiserConnect with nearby energizer using Bluetooth to check voltage, turn on and off, and configure the remote address
Connect to energizer remotely over the internet to receive notifications when voltage drops. Check voltage remotely, and turn on and off remotely (Requires Wi-Fi network coverage).
Monitor and control the energizer from your phone
Use the Datamars Livestock Farm App to connect to the energizer and see the fence voltage in real-time, configure the energizer settings, and connect the energizer to the Wi-Fi network.
Once the energizer is connected to the internet, it sends a notification when fence voltage drops, so issues can be resolved quickly.
In conclusion, If a fault is found on the fence line, use the app to turn the energizer off right from where you’re standing to fix the fault, then turn the energizer back on and check the voltage is back to normal.
-
Stafix AM1 Alarm Monitor
KSh23,000.00Add to cartDescription
Stafix AM1 Alarm MonitorStafix AM1 Alarm Monitor from Mtech Networks Nairobi, At Mtech we have all-electric fencing solutions you may require to safeguard your property.
Stafix AM1 Alarm Monitor unit pulses and operates like a normal electric fence energizer, except that the voltages are under 50 V, making it intrinsically safe and below any perceived dangerous high voltages.
Stafix AM1 Alarm Monitor has been a huge success as installers faced with sites under the new SANS electric fencing act, that were deemed dangerous as high voltage wires were exposed to public access areas, now have a solution.
Stafix AM1 Alarm Monitor installers were previously faced with either removing the fence or installing an expensive barrier fence. With the ZLM monitors, fence sections below 1.5 m could be wired into the JVA monitor and still be fully monitored and alarmed without any dangerous shocks.
Stafix AM1 Alarm Monitor has been very successful with many housing estates, industrial companies and old age homes. Even some government organizations have replaced certain energizers in their systems with JVA ZLM units to achieve their COC compliance.
Stafix AM1 Alarm Monitor TCP/IP interface and networkability, the ZLM4 is able to slot into any already networked perimeter patrol system.
Stafix AM1 Alarm Monitor specifications
Create multiple zones/sectors
Dynamic fence voltage monitoring
LED displays fence status
Relays for siren/strobe
Adjustable fence voltage delay and trip settings
12 V battery powered. -
Stafix M63r Electric Fence Energiser
KSh270,000.00Add to cartDescription
Stafix M63r Electric Fence Energiserthis energizer machine is powered by mains. It is not possible to use a battery like the X18i, X12i and others. Its reliable performance is unmatched and it delivers maximum power. It can be used to fence up to 500 acres or about 360 Km. It has a maximum output of up to 36 Joules and stored energy of up to 54 joules.
Cyclic Wave™ technology. Provides a clean, powerful pulse that maximizes the energy that travels down the fence line, resulting in continuous power right to the end of your fence for optimal livestock control
Bi-polar technology. Enables the user to power a fence system to perform exceptionally well in dry, low conductive soil
Remote capable. Using a Stafix fence remote (with remote capable Stafix energizers) enables you to switch the energizer on or off from anywhere along the fence line. This makes it easy to manage repairs and maintenance
Indicator lights. Easy to read light bar display provides an instant measure of the energizer output voltage for quick fence diagnostics. The LED display shows red when heavily loaded
Load response feature. Controls energizer output to match conditions, providing maximum fence voltage for effective stock control
Large terminals. Mounted on the front of the energizer casing for convenience, these large terminals are easily adjusted and accept up to two fence wires. The slotted terminals make inserting wires and getting a good connection easy
Low impedance. Designed to deliver power to the end of the fence even under heavy load e.g. foliage, undergrowth
Low interference. Cyclic Wave™ technology delivers outstanding fence performance and helps to minimize electromagnetic interference in line with international EMC standards
Rugged design. Hi-tech components and advanced research and development have enabled us to make powerful energizers in a rugged, compact, polymer case
Half voltage terminal. -
Add to cart1.6mm Electric Fence Undergate Cable 100m
This U-Series high voltage insulated electric fencing cable is used to carry the voltage from the energizer to the electric fence in a safe and insulated manner. It can also be used to carry the voltage under gates to the next section of fence. This underground cable is suitable for use with galvanised wires, aluminium wires and all poly wires, poly ropes and poly tapes.
1.6mm Electric Fence Undergate Cable 100m specifications
**
Material
Solid heavy galvanised inner conductor
Roll size
25m
50m
100m
200m
500mColour
Black
Diameter
1.6mm
2.5mmResistance
1.6mm ** 98 Ohms/km
2.5mm ** 36 Ohms/km**
