Description

This product is not sent to some countries or areas, if the cart does not have available carriers, you can contact us here

3m lower section pivoting for the erection of a 360 tower.?
Guy wires are required for pivoting sections.
Features
Anchoring system with union nuts
Easy and quick mounting
Fully automated soldering
360 tower maximum height: 57m (as per calculation conditions)
The hot-dip galvanizing surface treatment provides enhanced durability in adverse corrosion conditions
Finished in White
Specifications
Description Upper section tower 360.?White color
Material

(1) Steel ST 37-2 ? 30 ext. x 2 mm esp. Re min. 235 N / mm2 – Rn min. 360/510 N / mm2

(2) Steel S 275 JR ? 9 mm esp. Re min. 275 N / mm2 – Rn min. 410/560 N / mm2

(3) Steel F626 (S 235) sheet 10 mm esp. Re min. 275 N / mm2 – Rn. 410/560 N / mm2

Finish Hot galvanized.?(White RAL 9002)
Weight 25 Kg?
Surface facing the wind 0.355 m2 x 1.2 coef. = 0.426 m2
