Mecer ME-20000-GT UPS, 20KVA 3 Phase Online Smart UPS

Related products

•

  Mecer ME-10000-WPTU UPS, 10KVA Pro Online Tower Smart UPS

  KSh290,000.00

  Description
  Mecer ME-10000-WPTU 1KVA Pro Online Tower Smart-UPS

  Mecer ME-10000-WPTU 1KVA Pro Online Tower Smart UPS from the leading Mecer smart UPS in Nairobi, buy online, ME-10000-WPTU 1KVA Pro Online Tower Smart UPS.

  Mecer ME-10000-WPTU 10000VA / 8000W ON-LINE UPS (with AVR,Monitoring Software + Cable & Built-in Surge Protection) – Black. 12 V / 9 Ah batteries x16. Voltronic Power Winner Pro online pure sine wave UPS.

  ME-10000-WPTU 10000VA Specifications:

  Specifications and features
  Product Code ME-10000-WPTU
  CAPACITY 10000 VA / 8000 W
  PHASE Single phase with ground
  INPUT
  Input Voltage Range 110-300 VAC (Based on load at 50%); 176-300 VAC (Based on load at 100%)
  Nominal Voltage 208/220/230/240 VAC
  Frequency Range 46~54 Hz or 56~64 Hz
  Power Factor >= 0.99 @ Nominal Voltage (100% load)
  OUTPUT
  Voltage Regulation ± 1%
  Output Voltage 208/220/230/240 VAC
  Frequency Range (Batt. Mode) 50 Hz or 60 Hz ± 0.1 Hz
  Transfer Time : AC Mode to Battery Mode Zero
  Transfer Time : Inverter to Bypass Zero
  Transfer Time : Waveform (Batt. Mode) Pure Sine Wave
  Current Crest Ratio 3::1
  Harmonic Distortion <= 3% THD (Linear Load); <= 5% THD (Non-linear Load) Frequency Range (Synchronized Range) 46~54 Hz or 56~64 Hz Mecer ME-10000-WPTU 10000VA EFFICIENCY Battery Mode 0.91 AC Mode 0.93 Mecer ME-10000-WPTU 10000VA BATTERY Long-run Model : Battery Type Depending on the capacity of external batteries Long-run Model : Charging Current (max.) 1A/2A/4A/6A (Adjustable, 6A is only available for 16pcs batteries) Long-run Model : Charging Voltage 273 VDC ± 1% (Based on 20pcs bateries) Long-run Model : Numbers 16~20 (Adjustable) Standard Model : Battery Type 12 V / 9 Ah Standard Model : Charging Current (max.) 1A/2A Standard Model : Charging Voltage 218.4 VDC ± 1%, 273 VDC ± 1% Standard Model : Numbers 16, 20 Standard Model : Typical Recharge Time 9 hours recover to 90% capacity INDICATORS LCD Load level, Battery level, AC mode, Battery mode, Bypass mode, and Fault indicators ALARM Battery Mode Sounding every 4 seconds Low Battery Sounding every second Overload Sounding twice every second Fault Continuously sounding ENVIRONMENT Operating Humidity 0~95% RH @ 0- 40°C (non-condensing) Noise Level Less than 58dB @ 1 Meter PHYSICAL Standard Model : Dimension, D x W x H (mm) 442 x 190 x 688 Standard Model : Net Weight (kgs) 66, 76 Long-run Model : Dimension, D x W x H (mm) 442 x 190 x 318 Long-run Model : Net Weight (kgs) 16 MANAGEMENT Optional SNMP Power management from SNMP manager and web browser Smart RS-232/USB Supports Windows 2000/2003/XP/Vista/2008, Windows 7/8/10, Linux, and MAC Conclusion The Mecer ME-10000-WPTU is a 10KVA Pro Online Tower Smart UPS that offers advanced performance and reliable power protection for critical equipment. With its 10KVA capacity, it provides ample power backup to support a wide range of devices during power outages. The UPS operates in online double-conversion mode, ensuring consistent and clean power delivery to your connected equipment. It offers a high input power factor and low input current distortion, making it efficient and suitable for demanding environments.

  Add to cart

  Quick View
•

  Mecer ME-30000- GTU UPS, 30KVA 3 Phase Online Smart UPS

  KSh10,000,000.00

  Description
  Mecer ME-30000- GTU 30KVA 3 Phase Online Smart UPS

  Mecer ME-30000- GTU 30KVA 3 Phase Online Smart-UPS from the leading mecer UPS authorised dealer in Nairobi Kenya, buy  ME-30000- GTU 30KVA 3 Phase Online Smart UPS.

  Microprocessor control optimizes reliability
  Input power factor correction
  Output power factor 0.8
  Wide input voltage (110 V–300 V)
  Converter mode available
  ECO mode for energy saving
  Generator compatible
  Charger capacity expansion to 6A for long-run models
  Smart SNMP works well with either USB or RS-232 together
  Comprehensive display allows easy monitoring and access of UPS status

  Add to cart

  Quick View
•

  Mecer ME-1000-GTU UPS, 1KVA Online Smart UPS

  KSh48,000.00

  Description
  Mecer ME-10000-GTU 1KVA Online Smart UPS

  Mecer ME-10000-GTU 1KVA Online Smart UPS from the leading Mecer 1KVA smart UPS dealer in Nairobi Kenya,  ME-10000-GTU 1KVA Online Smart UPS .

  MECER 1000VA (800W)Smart UPS (with AVR,Monitoring Software + Cable & Built-in Surge Protection) -Serial and USB standard 2 x12V 9Ah batteries Mecer 1000VA On-Line Tower UPS (ME-1000-WPTU) – Capacity: 1000VA / 800W, Battery Type:

  12V/9Ah, Frequency Range: 40Hz ~ 70 Hz, Includes AVR, Monitoring Software, Cables & Built-in Surge Protection, Black Colour – Power Cable Not Include.

  Mecer ME-10000-GTU 1KVA Online Smart UPS Specifications
  Model: Mecer ME-10000-GTU
  Capacity: 1KVA/900W
  Technology: Online Double Conversion
  Input Voltage: 220/230/240VAC
  Output Voltage: 220/230/240VAC
  Frequency: 50/60Hz (auto-sensing)
  Waveform: Pure Sine Wave
  Transfer Time: 0ms (Online Mode)
  Battery Type: Sealed Lead-Acid
  Battery Voltage: 12V
  Battery Quantity: 6
  Backup Time: Dependent on load
  Charging Time: 4-6 hours to 90% capacity
  Protection: Overload, Short Circuit, Over Voltage, Under Voltage, Over Temperature
  Communication Ports: USB, RS232, SNMP (optional)
  Software: PowerMaster (included)
  Display: LCD panel with status indicators
  Audible Alarms: Battery Mode, Low Battery, Overload
  Operating Temperature: 0°C to 40°C
  Dimensions: 438mm x 145mm x 220mm (W x H x D)
  Weight: 16kg (without batteries)

  Conclusion

  The Mecer ME-10000-GTU 1KVA Online Smart UPS is a reliable and high-performance uninterruptible power supply (UPS) designed to provide reliable backup power for critical equipment. With a capacity of 1KVA/900W, it offers sufficient power to support small to medium-sized devices and systems.

  Using online double conversion technology, the UPS provides continuous and clean power, ensuring stable and reliable operation even in challenging power conditions. It features a pure sine wave output waveform,

  Add to cart

  Quick View
•

  Mecer 10KVA 3 Phase Online Smart UPS

  KSh450,000.00

  Description
  Mecer 10KVA 3 Phase Online Smart UPS

  Mecer 10KVA 3 Phase Online Smart UPS from the leading mecer UPS dealer in Nairobi Kenya, buy online and have it delivered, 10KVA 3 Phase Online Smart UPS.

  Mecer 10KVA 3 Phase Online UPS is a high frequency unit specifically designed for servers, data-center critical network devices, sensitive electronic equipment, telecom, banks, hospitals etc.

  SKU ME-3000-WPTU
  WEIGHT 27.600
  PHYSICAL DIMENSIONS 421 x 190 x 318 (mm)
  CAPACITY 3000 VA / 2400 W
  VOLTAGE RANGE LOW LINE TRANSFER 160VAC/140VAC/120VAC/110VAC±5% ( based on load percentage 100% – 80 % / 80 % – 70 % / 70 – 60 % / 60 % – 0)
  VOLTAGE RANGE LOW LINE COMEBACK 168VAC/148VAC/128VAC/118VAC ± 5 % ( based on load percentage 100% – 80 % / 80 % – 70 % / 70 – 60 % / 60 % – 0)
  VOLTAGE RANGE HIGH LINE TRANSFER 300 VAC ± 5 %
  VOLTAGE RANGE HIGH LINE COMEBACK 290 VAC ± 5 %
  FREQUENCY RANGE 40Hz ~ 70 Hz
  PHASE Single phase with ground
  POWER FACTOR ** 0.99 @ nominal voltage (input voltage)
  OUTPUT VOLTAGE 200/208/220/230/240VAC
  AC VOLTAGE REGULATION (BATT. MODE) ±1% (Batt. Mode)
  FREQUENCY RANGE (SYNCHRONIZED RANGE) 47 ~ 53 Hz or 57 ~ 63 Hz
  FREQUENCY RANGE (BATT. MODE) 50 Hz ± 0.25 Hz or 60Hz ± 0.3 Hz
  OVERLOAD Sounding twice every second
  CURRENT CREST RATIO 3:1
  HARMONIC DISTORTION ** 3 % THD (linear load) ** 6 % THD (non-linear load)
  WAVEFORM (BATT. MODE) Pure Sinewave
  AC TO DC Zero
  INVERTER TO BYPASS 4 ms (Typical)
  AC MODE 90%
  BATTERY MODE 88%
  BATTERY TYPE 12 V / 9 AH
  NUMBERS 6
  RECHARGE TIME 4 hours recover to 90% capacity (Typical)
  CHARGING CURRENT 1.0 A (max.)
  CHARGING VOLTAGE 82.1 VDC ± 1%
  BATTERY TYPE & NUMBERS No
  CHARGING CURRENT No
  CHARGING VOLTAGE No
  HUMIDITY 20-90 % RH @ 0- 40°C (non-condensing)
  NOISE LEVEL Less than 50dBA @ 1 Meter
  OPTIONAL USB/RS-232 PORT Supports Windows® 2000/2003/XP/Vista/2008/7, Linux, Unix and MAC
  OPTIONAL SNMP Power management from SNMP manager and web browser
  Run-times of ME-3000-WPTU 3kVA
  Model Number of Batteries Encasement 100% Load Backup Time 75% Load Backup Time 50% Load Backup Time 25% Load Backup Time
  ME-3000-WPTU 6 Internal 4.5 Minutes 7 Minutes 13 Minutes 31 Minutes

  • Online-Double conversion • Supports all kinds of load, high overload capability • Fully digitally controlled with 3 DSP’s for IGBT rectifier, inverter and battery charger • Digital Circulating Current Control Technology, Increasing Parallel Reliability • Green Power Technology, High Input Power Factor, Low Current THD, High Efficiency • Intellegent self-diagnosis function, All kinds of fault protection, Large event log capability • Redundant Design of Power Model Fans, Increasing system reliability • High MTBF (Mean Time Between Failures) (>200,000 HOURS), Low MTTR (Mean Time To Repair

  Add to cart

  Quick View
•

  Mecer 10KVA Single Phase Online Smart UPS

  KSh240,000.00

  Description
  Mecer 10KVA Single Phase Online Smart UPS

  Mecer 10KVA Single Phase Online Smart UPS from the leading mecer smart UPS authorized dealer in Kenya, buy online Mecer 10KVA Single Phase Online Smart UPS

  Mecer 10KVA Single Phase Online Smart UPS specifications
  Model: Mecer 10KVA Single Phase Online Smart UPS.
  Capacity: 10KVA (10,000VA)
  Technology: Online double-conversion
  Input Voltage: 220/230/240VAC
  Input Frequency: 40-70Hz
  Output Voltage: 220/230/240VAC
  Output Frequency: 50/60Hz ±0.2Hz
  Output Waveform: Pure sine wave
  Efficiency: ≥ 90% (AC mode), ≥ 93% (Battery mode)
  Battery Type: Sealed lead-acid maintenance-free battery
  Battery Voltage: 240VDC
  Transfer Time: Zero transfer time.
  Communication Ports: USB, RS232, SNMP
  LCD Display: Yes, with real-time status information
  Protection: Overload, short circuit, battery low voltage, over-temperature
  Backup Time: Depends on the load and battery capacity
  Operating Temperature: 0°C to 40°C
  Dimensions: Varies depending on the model
  Weight: Varies depending on the model

  Conclusion

  The Mecer 10KVA Single Phase Online Smart UPS is a high-performance uninterruptible power supply designed to provide reliable and efficient power protection for critical equipment. With its online double-conversion technology, it ensures a continuous and clean power supply, safeguarding sensitive devices from power disruptions, voltage fluctuations, and surges.

  The UPS offers a capacity of 10KVA, providing ample power for demanding applications. It features a pure sine wave output waveform, delivering stable and high-quality power to connected devices. The UPS comes with communication ports such as USB, RS232, and SNMP, allowing for easy monitoring and management.



  Add to cart

  Quick View
