Splitters Nevoswitch 5x5x5 “F” 20dB
Shunt Nevoswitch 5x5x5 “F ” 20dB . Ref . 714903 Televes
This device complements nevoswitch multiswitch range , so that the installation is achieved expand to a larger number of users by optimizing the signal will reach each.
Highlights: ?
Zamak chassis that makes them immune to radiation.
scalable system for star topologies and waterfall.
Independent adjustment of the output level to each user (except range QUAD Compatible) .
ECO low-power mode .
ECO system has the consumption of the installation is reduced with decreasing the number of connected users. ? ?
Characteristics: ?
independent amplification lines .
Configurable.
Small size and compact design.
Multiple power options ( Jack , line VL , user input or terrestrial and output connectors ) independent level control on each output
