TELEVES 300mm Connecting Leads Kit
TELEVES
300mm Connecting Leads Kit
(x5 System Colour Coded Link Leads)
*Special Order! NCNR – Check Lead Time*
Kit composed of 5 coloured cables (red, yellow, black, white and green)
with 26 cm in length each.
Features:
Outer sheath of PVC
“Quick F” connectors
Cable conductors made of copper
