Ubiquiti Networks PBE-5AC-500 network antenna Directional antenna 27 dBi

Ubiquiti
PBE-5AC-500 – reliable AirMax solutions
The Ubiquiti PBE-5AC-500 device complements the AirMax PowerBeam AC series.
The device works in the 5 GHz band achieving 450 Mbps bandwidth levels.

Thanks to its efficiency and high quality the PBE-5AC-500 is perfect for
situations that require maximum bandwidth. The device sends data with a
maximum speed of 1000 Mbit/s. It is equipped with 1 Ethernet LAN (RJ-45)
port.

Work

The Ubiquiti AP/Bridge/CPE type devices comply with 802.11ac standards and
are AirMax protocol compliant. The PBE-5AC-500 is equipped with 136 MB of
internal memory.

Construction

The Ubiquiti devices are built from durable components which in turn leads
to high quality. It can be used at temperatures ranging from -40 to 70
degrees Celsius and humidity from 5% to 95%.

Antenna

The maximum gain of the antenna is 27 dBi. The use of InnerFeed technology
allows for the integration of the antenna emitter with the radio
module.

AirMax

The PowerBeam AC series devices uses AirMax technology which increases
their bandwidth capabilities.

Key features
works in the 5 GHz band
450+ Mbps bandwidth
25+ km range
27 dBi antenna gain

Use

The PBE-5AC-500 device can be used to create Point-to-Point links. It works
perfectly when maximum efficiency is required.

Power

The power consumption of the device is 8.5 W. Its modified construction
allows the beam to be more concentrated, which eliminates the problem of
crowded networks. The device supports PoE. The PBE-5AC-500 is FCC, IC and CE
certified.

Comparison


     PBE-5AC-300

  PBE-5AC-400

PBE-5AC-500

PBE-5AC-620

FREQUENCY 5 GHz 5 GHz 5 GHz 5 GHz
THROUGHPUT 450+ Mbps 450+ Mbps 450+ Mbps 450+ Mbps
RANGE 20+ km 25+ km 25+ km 30+ km
GAIN 22 dBi 25 dBi 27 dBi 29 dBi
DISH REFLECTOR 300 mm 400 mm 500 mm 620 mmN
NETWORKING INTERFACE (1) 10/100/1000 Ethernet Port (1) 10/100/1000 Ethernet
Port (1) 10/100/1000 Ethernet Port (1) 10/100/1000 Ethernet Port
