Mecer 10KVA Online Smart UPS

Name: Mecer 10KVA Online Smart UPS | +254720548999
Price: 270000.00 KES
Availability: InStock

KSh270,000.00

Description
Mecer 10KVA Online Smart-UPS

Mecer 10KVA Online UPS is a market changer when it comes to how we do things in our offices, Mecer 10KVA UPS keeps you working irrespective there is power or not When there is power interruption 10KVA mecer UPS can support office equipment for hours depending on equipment load.

Mecer UPS acts as a surge protector to companies’ most valued assets which are connected to a power grid, 10KVA mecer UPS acts as a stepdown when there is more circuit from the power grid.

10KVA mecer UPS helps you face the competition head-on. Competition is becoming so fierce in today’s economy that why power disruption may cost business so much, power surges may destroy machinery and other equipment when power keeps going on and off . Mtech Networks want you to stay on top of business with Meccer UPS.

this 10KVA UPS can help run the equipment for several hours when power goes off and also there is no abrupt power disruption to equipment.

Mecer 10KVA Online Smart-UPS specifications
Specifications and features
Product Code ME-10000-WPTU
CAPACITY 10000 VA / 8000 W
PHASE Single phase with ground
INPUT
Input Voltage Range 110-300 VAC (Based on load at 50%); 176-300 VAC (Based on load at 100%)
Nominal Voltage 208/220/230/240 VAC
Frequency Range 46~54 Hz or 56~64 Hz
Power Factor >= 0.99 @ Nominal Voltage (100% load)
OUTPUT
Voltage Regulation ± 1%
Output Voltage 208/220/230/240 VAC
Frequency Range (Batt. Mode) 50 Hz or 60 Hz ± 0.1 Hz
Transfer Time : AC Mode to Battery Mode Zero
Transfer Time : Inverter to Bypass Zero
Transfer Time : Waveform (Batt. Mode) Pure Sine Wave
Current Crest Ratio 3::1
Harmonic Distortion <= 3% THD (Linear Load); <= 5% THD (Non-linear Load) Frequency Range (Synchronized Range) 46~54 Hz or 56~64 Hz EFFICIENCY Battery Mode 0.91 AC Mode 0.93 BATTERY Long-run Model : Battery Type Depending on the capacity of external batteries Long-run Model : Charging Current (max.) 1A/2A/4A/6A (Adjustable, 6A is only available for 16pcs batteries) Long-run Model : Charging Voltage 273 VDC ± 1% (Based on 20pcs bateries) Long-run Model : Numbers 16~20 (Adjustable) Standard Model : Battery Type 12 V / 9 Ah Standard Model : Charging Current (max.) 1A/2A Standard Model : Charging Voltage 218.4 VDC ± 1%, 273 VDC ± 1% Standard Model : Numbers 16, 20 Standard Model : Typical Recharge Time 9 hours recover to 90% capacity INDICATORS LCD Load level, Battery level, AC mode, Battery mode, Bypass mode, and Fault indicators ALARM Battery Mode Sounding every 4 seconds Low Battery Sounding every second Overload Sounding twice every second Fault Continuously sounding ENVIRONMENT Operating Humidity 0~95% RH @ 0- 40°C (non-condensing) Noise Level Less than 58dB @ 1 Meter PHYSICAL Standard Model : Dimension, D x W x H (mm) 442 x 190 x 688 Standard Model : Net Weight (kgs) 66, 76 Long-run Model : Dimension, D x W x H (mm) 442 x 190 x 318 Long-run Model : Net Weight (kgs) 16 MANAGEMENT Optional SNMP Power management from SNMP manager and web browser Smart RS-232/USB Supports Windows 2000/2003/XP/Vista/2008, Windows 7/8/10, Linux, and MAC Serial and USB standard with parallel kit 20 x12V 9Ah batteries True double-conversion online UPS Wide input voltage range (110-300 VAC) Input power factor correction 0.99 Output Power Factor 0.8 50Hz/60Hz frequency converter mode Programmable power management outlets Emergency power off function (EPO) ECO mode operation for energy saving (ECO) Charger capacity expansion to 8A for long-run models SNMP USB RS-232 multiple communications Smart battery charger design for optimized battery performance Selectable output voltage via LCD panel Hot-swappable battery design (only available for ME-1000-GRU/ME-2000-GRU/ME-3000-GRU)
