PAU Distributor 4 Outputs Connector F 9 dB Televes
PAU Distributor of 4 Outputs 519534 of Televes
This indoor installation splitter has 2 outputs with F connectors, suitable for SMATV signals. It has good shielding and improves through losses.
As it comes with PAU, it offers an additional 75 Ohms charged input for the connection of the second downspout. This user access point for distribution is used in collective ICT-2 installations.
Includes grounding screw and DC step from the output to the input. It can also be installed outdoors, as long as we put it inside a box (TEL4177).
The splitter has a 9 dB attenuation at 690 MHz. It can be installed on a wall, rack or assembled on a DIN rail. Its armored casing is made of zamak provides great shielding.
Technical Specifications of the Televes 519534 4-Output Distributor PAU
?
Frequency range MHz 5 … 2400
Number of outputs ? 4
Inputs/Bands ?
TERR SAT
Through losses dB
9 8
Rejection between taps dB
> 20 > 20
Max voltage Vdc 24
Max current mA 350
DC pass ? out.?in.
