Splitter F.O.1260…1650nm ?SC/APC? 32D 17dB
Splitter **ptico 32 outputs and 17 dB Televes. Ref.**TEL234650.
Range of optical distribution**networks for FTTx, PON, etc., ideal for mounting in boxes and racks (tray type accessories). Its main advantages are:
High reliability.
Low insertion loss.
High uniformity between outputs.
Made of single mode fiber (SM) of 900**m.
Meet ITU-T standards-G657A1.
Applications for telecommunications networks (FTTx, PON systems LAN, WAN).
Main features:
High reliability.
Low insertion losses.
Very Low PDL (polarization sensitivity).
Excellent uniformity.
Design and compact dimensions.
SC / APC Connectorization.
Made with 900 microns SM fiber, which gives ease of handling and resistance.
According to ITU-T G657A1, which provides its fibers a very small turning radius.
Applications:
Telecommunications networks (FTTH PON systems LAN, WAN).
Referencia 233750 ?233950 ?234450 ?234550 ?234650
N? de salidas No. of outputs ? 2 4 8 16 32
Conectores ?pticos de entrada y salida Input & output connectors Type SC/APC
Fibra Fiber Type Monomodo / Single-mode G657A1
Di?metro de la fibra Fiber diameter ? 900
Longitudes de onda de trabajo Working wavelength nm 1260 … 1650
P?rdidas de inserci?n Insertion loss (IL) dB ? 4.1 ? 7.5 ? 10.5 ? 13.5 ? 17.5
P?rdidas de retorno Return loss (RL) dB ??55
Uniformidad Uniformity dB ? 0.6 ? 0.8 ? 0.8 ? 1.2 ? 2
P?rdidas de polarizaci?n Polarization dependent loss (PDL) dB ? ? 0.3 ? ?
