  Dahua 32 Channel NVR, DHI-NVR4432-16P-4KS2 32 Channel Lite NVR – Kenya

  KSh37,000.00

  Dahua 32 Channel NVR,  DHI-NVR4432-16P-4KS2 32 Channel Lite NVR

  System

  Main Processor

  Industrial embedded micro-processor

  Operating System

  Embedded Linux

  Operation Interface

  Web; local GUI

  Perimeter Protection by Camera

  Performance

  16 channels

  AI Search

  Search for pictures by channel, time and event type

  SMD Plus by Camera

  Performance

  16/32 channels

  AI Search

  Search by target classification (human, vehicle)

  Video

  Access Channel

  16/32

  Network Bandwidth

  200 Mbps for access, 200 Mbps for storage and 96 Mbps for forwarding

  Resolution

  8MP, 6MP, 5MP, 4MP, 3MP, 1080p, 1.3MP, 720p, D1, and more

  Decoding Capability

  8 channels@1080p (30 fps)

  Video Output

  HDMI: 3840 × 2160; 1920 × 1080; 1280 × 1024; 1280 × 720
  VGA: 1920 × 1080; 1280 × 1024; 1280 × 720

  Multi-screen Display

  16-channel: 1/4/8/9/16
  32-channel: 1/4/8/9/16/25/36

  Third Party Camera Access

  Panasonic, Sony, Samsung, Axis, Pelco, Arecont, ONVIF, Canon and more

  Compression

  Video

  Smart H.265+; Smart H.264+; H.265; H.264

  Audio

  PCM; G.711A; G.711U; G.726

  Network

  Network Protocol

  HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; IP Search (supports Dahua IP camera, DVR, NVS, and more); P2P

  Mobile Phone Access

  Android; iOS

  Interoperability

  ONVIF (profile T/S/G); CGI; SDK

  Browser

  Chrome; IE9 or later; Firefox

  Record Playback

  Multi-channel Playback

  1/4/9/16

  Record Mode

  Manual; schedule (general; MD; alarm; MD & alarm; intelligent)

  Storage Method

  Local HDD and network

  Backup

  USB device

  Playback Function

  1. Play; pause; stop; fast forward; fast backward; rewind; play by frame
  2. Full screen; backup (cut/file) ; partially enlarge; audio on/off

  Storage

  Disk Group

  Yes

  Alarm

  General Alarm

  Motion detection; privacy masking; video loss; PIR alarm; IPC alarm

  Anomaly Alarm

  Camera offline; storage error; full storage; IP conflict; MAC conflict; login lock; network security anomaly

  Intelligent Alarm

  Perimeter protection; SMD; people counting; heat map

  Alarm Linkage

  Record; snapshot; IPC external alarm output; buzzer; log; preset; email

  External Port

  Audio Input

  1 channel, RCA connector

  Audio Output

  1 channel, RCA connector, which support voice intercom output

  HDD

  4 SATA III ports, up to 10 TB for a single HDD. The maximum HDD capacity varies with environment temperature

  Alarm Input

  16 channels

  Alarm Output

  4 channels

  RS-232

  1 channel, used to debug and pass through serial data

  RS-485

  1 channel, used to control PTZ, and it supports multiple protocols

  USB

  1 front USB 2.0 port, 1 rear USB 3.0 port

  HDMI

  1

  VGA

  1

  Network

  1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet port

  PoE

  16 ports (IEEE802.3at/af)

  General Parameter

  Power Supply

  Single, 100V–240V AC, 50 Hz–60 Hz

  Power Consumption

  NVR: < 13.7W (without HDD) PoE: Max 25.5W for single port, 150W in total Net Weight 4.7 kg (10.4lb) (without HDD) Gross Weight 7.5 kg (16.5 lb) (without HDD) Product Dimensions 440.0 mm × 414.6 mm × 76.0 mm (17.3? × 16.3? × 3.0?) Package Dimensions 522 mm × 492 mm × 200 mm (20.6? × 19.4? × 7.9?) Operating Temperature -10°C to +55°C (+14°F to +131°F) Storage Temperature 0°C to +40°C (+32°F to +104°F) Operating Humidity 10%–93% (RH) Storage Humidity 30%–85% (RH) Operating Altitude 3,000 m (9,843 ft) Certifications CE: EN55032; EN55024; EN50130-4; EN60950-1 FCC: Part 15 Subpart B; ANSI C63.4-2014 UL: UL 60950-1
