LC/UPC 1mtr Single Mode Pigtails
KSh155.00
Hammer Energizers
Description
LC/UPC 1mtr Single Mode Pigtails
The LC/UPC 1mtr Single Mode Pigtails are high-performance fiber optic cables specifically designed for efficient and reliable connectivity in telecommunications and networking applications. Featuring LC/UPC connectors, these pigtails ensure low insertion loss, making them suitable for long-distance signal transmission with minimal degradation.
With a length of 1 meter (approximately 3.28 feet), these pigtails are ideal for various installation scenarios, including data centers, telecommunications networks, and fiber optic patching. Constructed from single mode fiber with a core diameter of 9/125µm, they facilitate high bandwidth and support efficient data transfer over extended distances.
Optimized for performance, the pigtails typically exhibit an insertion loss of ≤ 0.3 dB, ensuring that signal integrity is maintained throughout the connection. Additionally, their return loss of ≥ 50 dB effectively minimizes signal reflections, enhancing overall transmission quality. The UPC polishing of the connectors further improves optical performance, ensuring minimal contact loss during connections.
Housed in a durable jacket made from either PVC or LSZH (Low Smoke Zero Halogen) material, these pigtails are designed for safety and flexibility in various installation environments. They can operate effectively across a wide temperature range, typically from -40°C to +70°C, making them suitable for both indoor and outdoor applications.
The LC/UPC 1mtr Single Mode Pigtails comply with industry standards such as Telcordia GR-326 and are rigorously factory tested to ensure quality and reliability. Each pigtail is carefully packaged to prevent damage during transport, allowing for immediate deployment upon arrival.
Connector A LC Connector B Unterminated
Fiber Mode 9/125 ?m Fiber Count Simplex
Fiber Grade G.652.D Minimum Bend Radius 30 mm
Polish Type UPC Cable Diameter 0.9 mm
Cable Jacket PVC Jacket Color Yellow
Wavelength 1310 nm/1550 nm Durability >1000 Times
Insertion Loss ?0.3 dB Interchangeability ?0.2 dB
Return Loss ?50 dB Vibration ?0.2 dB
Operating Temperature -40~75°C Storage Temperature -45~85°C
