RJ45 UTP Cat 6 Female Data Connector. Mounting type…
KSh15,342.00
RJ45 UTP Cat 6 female connector, reusable and easy to connect since no specific tools are required. The connector allows self-crimping by rotating the wing nut built into the rear part. Supplied in 10-unit professional plastic box.
RJ45 UTP Cat 6 female connector, reusable and easy to connect since no specific tools are required. The connector allows self-crimping by rotating the wing nut built into the rear part.
Supplied in 10-unit professional plastic box.
Highlights
Wing nut-type connector: the rotation of the wing nut guarantees the necessary fixation and mechanical reliability
No tools required: crimping is done by turning the wingnut with the fingers
Reusable: can be removed and reinstalled without deteriorating or losing functionality
Multiple-connection guaranteed without losses
Main features
Optimal for Cat 6 UTP, Cat 5e UTP and Cat 5 UTP
Front (180?) cable input
Labels with connection diagrams (A or B) are included on the connector
50 microns gold-plated pins
Discover
Compatibility of RJ45 connectors with Televes data cables:
Reference 219602 219701 219502 219901 219910 212201 2123 212302 212305 212310 212101 219302 219102 219312 219322
Female connectors
209905 ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?
209901 ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?
209921 ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?
209903 ?* ?* ? ?* ?* ?* ?* ?* ?* ?* ? ? ? ? ?
209923 ?* ?* ? ?* ?* ?* ?* ?* ?* ?* ? ? ? ?* ?
Male connectors
209902 ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?
209904 ?* ?* ? ?* ?* ?* ?* ?* ?* ?* ? ? ? ? ?
209922 ?* ?* ? ?* ?* ?* ?* ?* ?* ?* ? ? ? ? ?
209924 ?* ?* ?* ?* ?* ?* ?* ?* ?* ?* ?* ? ? ?* ?
? Compatible
?* Compatible, but there are better choices
? Incompatible
The RJ45 is a connector commonly used in structured cable networks. With up to 8 connection pins, it is adequate both for data networks (8 pairs), as well as telephone networks (2 pairs). It is usually used in networks compliant with standards TIA/EIA-568-B.
Technical specifications
Data connector model Female
Data connector type RJ45
Categorie Cat 6
Connector shielding No
Voltage max. Vac 125
Max. current mA 1.5
Contact resistance m? 100
Insulation resistance M? 1000
Dielectric strength (60Hz/1min) Vac 750
Conductor Type AWG 22…26
Special tool required No
Durability (connection cycles) 750
Reusable Yes
Cable output 180?
Colour White/Orange
