Streamer with remultiplexing DVBT/T2 – IP, with CI Televes
KSh423,500.00
Streamer generating an IP encapsulated output from the multiplexing of the services available in 4 different DVB-T or DVB-T2 muxes.
Streamer generating an IP encapsulated output from the multiplexing of the services available in 4 different DVB-T or DVB-T2 muxes.
The encrypted channels are transformed into free IP services through the CI interface and the appropriate CAM module. Depending on the CAM type used (standard/professional), one or several services may be opened for free visualization.
The system will encompass a power supply and some streamer modules depending on the number of services to be distributed.
Highlights
32 IP streams SPTS
DiSEqC 1.0 for multiswitches control
Service decryption by insertion of a PCMCIA module
Access to the headend configuration through a self-created WiFi network (using the kit with ref.216802)
Internal switch for IP out Daisy chain of serveral modules
Embedded user web interface for module configuration:
Configuration of the entire headend selecting one of the module as a master
Automatic detection of the modules that are connected to the master
Cloning function to replicate configurations between modules and headends
Main features
Selection of services among the 4 input muxes to distribute in streaming
Provides flow information of each service to estimate the global output flow of the module
Device monitoring and signal status LEDs
Specifications
DVB-T/DVB-T2
INPUT Input frequency MHz 150…862
Frequency steps MHz 125, 166 (Select.)
In/Out connectors ?F? female
Input impedance ? 75
Preamplifiers power supply Vdc 0, 12, 24 (Select.)
Input level dBm -60 to -20
Through losses (typ.) dB < 1,5
Bandwidth DVB-T MHz 6, 7, 8
DVB-T2 1.7, 5, 6, 7, 8
Input SWR dB 10
IP OUT Mode Multicast/Unicast
Format SPTS
Protocol IPv4, UDP, DHCP
Number of IP services Max. 32
Connectors 2 X RJ45 (1 GB Ethernet 1000 BaseT)
GENERAL Consumption 24Vdc (Base+CAM+Previous) mA 700 (500+100+100)
Protection index IP IP20
Temperature range ?C 0...45
