1 X 8 PVC 0.9mm fiber jacket SC/PC Rack Splitter connectors – Kenya
KSh7,500.00
1 X 8 PVC 0.9mm fiber jacket SC/PC Rack Splitter connectors?
1 X 8 PVC 0.9mm fiber jacket SC/PC Rack Splitter connectors from the leading fiber dealer in Nairobi kenya, buy online 1 X 8 PVC 0.9mm fiber jacket SC/PC Rack Splitter connectors and have it delivered.
PLC splitter is a type of optical power management device that is fabricated using silica optical waveguide technology to distribute optical signals from Central Office (CO) to multiple premise locations.
?
Blockless PLC splitter has stronger fiber protection than bare fiber splitter, which is a miniaturization result of cassette splitter. It?s mainly used for various connection and distribution boxes or network cabinets.
?
Product Specification
?
Package Style Mini Module Configuration Type 1?8
Fiber Type Singlemode G.657A1 Connector Type SC/APC
Input/Output Fiber Diameter 900?m Input/Output Fiber Length 1.5m
Insertion Loss ?10.6dB Return Loss ?50dB
Loss Uniformity ?0.8dB Directivity ?55dB
Polarization Dependent Loss ?0.2dB Temperature Dependent Loss ?0.5dB
Wavelength Dependent Loss ?0.3dB Operating Bandwidth 1260~1650nm
Split Ratio 50/50 Steel Tube Dimensions (HxWxD) 0.16?x2.36?x0.28? (4x60x7mm)
Operating Temperature -20~70?C Storage Temperature -40~85?C
1 X 8 PVC 0.9mm fiber jacket SC/PC Rack Splitter connectors?
1 X 8 PVC 0.9mm fiber jacket SC/PC Rack Splitter connectors from the leading fiber dealer in Nairobi kenya, buy online 1 X 8 PVC 0.9mm fiber jacket SC/PC Rack Splitter connectors and have it delivered.
PLC splitter is a type of optical power management device that is fabricated using silica optical waveguide technology to distribute optical signals from Central Office (CO) to multiple premise locations.
?
Blockless PLC splitter has stronger fiber protection than bare fiber splitter, which is a miniaturization result of cassette splitter. It?s mainly used for various connection and distribution boxes or network cabinets.
?
Product Specification
?
Package Style Mini Module Configuration Type 1?8
Fiber Type Singlemode G.657A1 Connector Type SC/APC
Input/Output Fiber Diameter 900?m Input/Output Fiber Length 1.5m
Insertion Loss ?10.6dB Return Loss ?50dB
Loss Uniformity ?0.8dB Directivity ?55dB
Polarization Dependent Loss ?0.2dB Temperature Dependent Loss ?0.5dB
Wavelength Dependent Loss ?0.3dB Operating Bandwidth 1260~1650nm
Split Ratio 50/50 Steel Tube Dimensions (HxWxD) 0.16?x2.36?x0.28? (4x60x7mm)
Operating Temperature -20~70?C Storage Temperature -40~85?C
