2X32 Bare PLC Steel Tube 250µm Single Mode Fiber Splitter – Kenya
KSh22,000.00
2X32 Bare PLC Steel Tube 250µm Single Mode Fiber Splitter
2X32 Bare PLC Steel Tube 250µm Single Mode Fiber Splitter from the leading fiber dealer in Nairobi Kenya, buy online 2X32 Bare PLC Steel Tube 250µm Single Mode Fiber Splitter and have it delivered at your doorstep.
Bare fiber plc splitter 2×32 PLC Fiber Optic Splitter Steel Tube Fiber optic splitters play an increasingly significant role in many of today’s optical network topologies. 2X32 Bare PLC Steel Tube 250µm Single Mode Fiber Splitter provides capabilities that help users maximize the functionality of optical network circuits from FTTH systems to traditional optical networks.
2X32 Bare PLC Steel Tube 250µm Single Mode Fiber Splitter And usually they are placed in the central office or in one of the distribution points (outdoor or indoor)
Steel Tube PLC Splitter, Plc Splitter Steel Tube suppliers/factory, wholesale high-quality products of Tube Type Fiber Optic Splitter R & D and manufacturing, we have the perfect after-sales service and technical support. Look forward to your cooperation!
Product Specification
Package Style Steel Tube, Bare Fiber Configuration Type 2×32
Fiber Grade Singlemode G.657A1 Connector Type None
Fiber Type Ribbon Fiber Temperature Operating -20~70°C Storage -40~85°C
Fiber Diameter 250**m Input/Output Fiber Length 1.5m
Insertion Loss **4.0dB Return Loss **50dB
Loss Uniformity **0.4dB Directivity **55dB
Polarization Dependent Loss **0.2dB Temperature Dependent Loss **0.5dB
Wavelength Dependent Loss **0.3dB Operating Bandwidth 1260~1650nm
Split Ratio 50/50 Steel Tube Dimensions (HxWxD) 0.16**x1.57**x0.16** (4x40x4mm)
2X32 Bare PLC Steel Tube 250µm Single Mode Fiber Splitter
2X32 Bare PLC Steel Tube 250µm Single Mode Fiber Splitter from the leading fiber dealer in Nairobi Kenya, buy online 2X32 Bare PLC Steel Tube 250µm Single Mode Fiber Splitter and have it delivered at your doorstep.
Bare fiber plc splitter 2×32 PLC Fiber Optic Splitter Steel Tube Fiber optic splitters play an increasingly significant role in many of today’s optical network topologies. 2X32 Bare PLC Steel Tube 250µm Single Mode Fiber Splitter provides capabilities that help users maximize the functionality of optical network circuits from FTTH systems to traditional optical networks.
2X32 Bare PLC Steel Tube 250µm Single Mode Fiber Splitter And usually they are placed in the central office or in one of the distribution points (outdoor or indoor)
Steel Tube PLC Splitter, Plc Splitter Steel Tube suppliers/factory, wholesale high-quality products of Tube Type Fiber Optic Splitter R & D and manufacturing, we have the perfect after-sales service and technical support. Look forward to your cooperation!
Product Specification
Package Style Steel Tube, Bare Fiber Configuration Type 2×32
Fiber Grade Singlemode G.657A1 Connector Type None
Fiber Type Ribbon Fiber Temperature Operating -20~70°C Storage -40~85°C
Fiber Diameter 250?m Input/Output Fiber Length 1.5m
Insertion Loss ?4.0dB Return Loss ?50dB
Loss Uniformity ?0.4dB Directivity ?55dB
Polarization Dependent Loss ?0.2dB Temperature Dependent Loss ?0.5dB
Wavelength Dependent Loss ?0.3dB Operating Bandwidth 1260~1650nm
Split Ratio 50/50 Steel Tube Dimensions (HxWxD) 0.16?x1.57?x0.16? (4x40x4mm)
