APC Easy UPS 3S 20kVA 400V 3:3 UPS ( E3SUPS20KHB1) – Kenya

Related products

•

  APC Easy UPS 3S 20kVA 400V 3:3 UPS ( E3SUPS20KHB1) – Kenya

  KSh12,000,000.00

  APC Easy UPS 3S 20kVA 400V 3:3 UPS ( E3SUPS20KHB1)

  APC Easy UPS 3S 20kVA 400V 3:3 UPS ( E3SUPS20KHB1) High-efficiency 3-phase UPS with internal batteries providing a runtime of 15 minutes. The UPS features advanced product features, competitive specifications,

  Easy UPS 3S 20 kVA 400 V 3:3 UPS with internal batteries – 15 minutes runtime high-efficiency 3-phase UPS with internal batteries providing a runtime of 15 minutes.

  Easy UPS 3S 20 kVA UPS features advanced product features, competitive specifications, and robust electrical design, making business continuity easy in the data center or electrical room.

  APC Easy UPS 3S 20kVA is exceptionally easy to install, operate, maintain, and service 20 kVA UPS, ideal for small and medium businesses. Includes dust filter and conformance coated boards for harsh environments.

  APC Easy UPS 3S 20kVA For battery runtime details, see the runtime charts published under the Documents tab.

  APC Easy UPS 3S 20kVA specifications
  Main
  acoustic level
  63 dBA

  battery curve
  B

  battery type
  External battery system

  bypass type
  Built-in maintenance bypass

  product certifications
  CE EAC RCM WEEE

  crest factor
  3 : 1

  curve equation
  Efficiency

  curve fixed loss
  0.0057

  curve load maximum
  100 %
  crest factor
  3 : 1

  curve equation
  Efficiency

  curve fixed loss
  0.0057

  curve load maximum
  100 %

  curve load minimum
  1 %

  curve proportional loss
  0.0209

  curve square loss
  0.0256

  curve test cond ID
  Curve fit to measured efficiency data. All measurements taken in normal operating mode, at typical environmental conditions, with 400V 50Hz input and 400V 50Hz balanced resistive load (PF = 1.0) output.

  curve X-axis maximum
  100 %

  curve X-axis minimum
  0 %

  curve X-axis title
  Load

  curve X-axis units
  Percentage

  curve Y-axis maximum
  100 %

  curve Y-axis minimum
  50 %

  curve Y-axis title
  Efficiency

  curve Y-axis units
  Percentage

  extended runtime
  0

  maximum input current
  55 A

  Maximum configurable power in VA
  30000 VA

  Maximum configurable power in W
  30000 W

  maximum short-circuit current
  10 kA

  liquid value
  0

  load power factor
  0.9 leading to 0.9 lagging

  mounting mode
  Not rack-mountable

  mounting preference
  No preference

  number of battery filled slots
  0

  number of battery free slots
  0

  cos phi
  0.99

  depth
  80 cm

  height
  77 cm

  Number of power module filled slots
  0

  Number of power module free slots
  0

  net weight
  60 kg

  rated power in VA
  30000 VA

  rated power in W
  30000 W

  width
  25 cm

  operating altitude
  0…3281 ft

  output overload operation
  10 minutes at 125% and 60 seconds at 150%

  ambient air temperature for operation
  0…40 °C

  ambient air temperature for storage
  -15…40 °C

  storage altitude
  0.00…14999.82 m

  standards
  IEC 62040-1-1 IEC 62040-2 IEC 62040-3 IEC 62040-4 ISTA 2B

  UPS size
  WS

  UPS type
  Double conversion online

  graph display
  1

  redundant
  No

  show note OP temperature
  No

  two post mountable
  0


  No

  colour
  White

  input voltage limits
  304…477 V

  input voltage
  400 V 3 phases

  IP degree of protection
  IP20

  network frequency
  45…65 Hz

  output voltage
  400 V 3 phases

  provided equipment
  Dust filter Installation guide

  relative humidity
  0…95 % non-condensing

  Battery power in VAH
  0 VAh runtime

  inputvolt_other
  380 V 415 V

  outputvolt_other
  380 V 415 V

  harmonic distortion
  Less than 3 %

  Environment
  heat dissipation
  1410 Btu/h

  Output
  output frequency
  50 Hz sync to mains 60 Hz sync to mains

  Packing Units
  Package 1 Weight
  77 kg

  Package 1 Height
  101.5 cm

  Package 1 width
  40 cm

  Package 1 Length
  98.2 cm

  Offer Sustainability
  EU RoHS Directive
  Pro-active compliance (Product out of EU RoHS legal scope) EU RoHS Declaration

  Mercury free
  Yes

  RoHS exemption information
  Yes

  China RoHS Regulation
  China RoHS declaration Product out of China RoHS scope. Substance declaration for your information

  WEEE
  The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins

  Optimized Energy Efficiency
  Energy efficient product

  BrandAPC
  Part NumberE3SUPS20KHB1
  ModelEasy UPS 3S
  Output Power Capacity20.0kWatts / 20.0kVA
  Other Output Voltages380, 415
  TopologyDouble Conversion Online
  Interface Port (s)E3S_Parallel, E3S_TempSensor
  Battery TypeVRLA
  Input Frequency45 – 65 Hz
  Input Voltage range for main operations304 – 477V
  Maximum Dimension H x W x D (mm)140 CM x 38 CM x 92.8 CM
  Shipping Dimension H x W x D (mm)164 CM x 56.3 CM x 101.4 CM
  Net Weight446 KG
  Shipping Weight494 KG
  ColorWhite
  Operating Relative Humidity0 – 95 (non-condensing) %
  Operating Temperature0 – 40 °C
  Storage Elevation0-15000meters
  Storage Relative Humidity0 – 95 (non-condensing) %
  Storage Temperature-15 – 40 °C
  Protection ClassIP 20
