Hikvision DS-7208HGHI-M1 8 Channel 720p 1U H.265 Digital Video Recorder – Kenya
KSh9,000.00
Hikvision DS-7208HGHI-M1 8 Channel 720p 1U H.265 Digital Video Recorder
Model: DS-7208HGHI-M1
Channels: 8
Video Input: 8-ch
Video Compression: H.265+/H.265/H.264+/H.264
Analog and HD-TVI Video Input: 8-ch, up to 720p resolution
Supported Camera Types: Support HDTVI input: 720p/25Hz, 720p/30Hz, Support AHD input: 720p/25Hz, 720p/30Hz, support CVBS input
Audio Input: 1-ch, RCA (2.0 Vp-p, 1 K**)
Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1 K**), (using the first audio input)
HDMI/VGA Output: 1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
Encoding Resolution: When 720p Lite mode not enabled: 720p/WD1/4CIF/VGA/CIF, When 720p Lite mode enabled: 720p/VGA/WD1/4CIF/CIF
Frame Rate: Main stream: When 720p Lite mode not enabled: For 720p stream access: 720p/WD1/4CIF/VGA/CIF@12fps; When 720p Lite mode enabled: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
Sub-stream: WD1/4CIF@12fps; CIF/QVGA/QCIF@25fps (P)/30fps (N)
Video Bit Rate: 32 Kbps-6 Mbps
Audio Output: 1-ch, RCA (Linear, 1 K**)
Audio Bit Rate: 64 Kbps
Dual-Stream: Support
Stream Type: Video, Video & Audio
Synchronous Playback: 8-ch
Playback Resolution: 720P/VGA/WD1/4CIF/CIF
Network Interface: 1; 10M / 100M self-adaptive Ethernet interface
Network Protocol: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
Network Incoming Bandwidth: 32 Mbps
Remote Connections: 128
USB Interface: 2 × USB 2.0
Capacity: Up to 6 TB capacity for each disk
SATA: 1 SATA interface
eSATA: 1 eSATA interface
Power Supply: 12 VDC
Consumption: ** 20 W
Working Temperature: -10 °C to +55 °C (14 °F to 131 °F)
Working Humidity: 10% to 90%
Chassis: 1U chassis
Dimensions: 260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch)
Weight: ** 1.2 kg (2.6 lb)
Installation: Desktop installation
Warranty: 2-year warranty
Mobile Monitoring: Hik-Connect or iVMS-4500
Hikvision DS-7208HGHI-M1 8 Channel 720p 1U H.265 Digital Video Recorder
Model: DS-7208HGHI-M1
Channels: 8
Video Input: 8-ch
Video Compression: H.265+/H.265/H.264+/H.264
Analog and HD-TVI Video Input: 8-ch, up to 720p resolution
Supported Camera Types: Support HDTVI input: 720p/25Hz, 720p/30Hz, Support AHD input: 720p/25Hz, 720p/30Hz, support CVBS input
Audio Input: 1-ch, RCA (2.0 Vp-p, 1 K?)
Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1 K?), (using the first audio input)
HDMI/VGA Output: 1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
Encoding Resolution: When 720p Lite mode not enabled: 720p/WD1/4CIF/VGA/CIF, When 720p Lite mode enabled: 720p/VGA/WD1/4CIF/CIF
Frame Rate: Main stream: When 720p Lite mode not enabled: For 720p stream access: 720p/WD1/4CIF/VGA/CIF@12fps; When 720p Lite mode enabled: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
Sub-stream: WD1/4CIF@12fps; CIF/QVGA/QCIF@25fps (P)/30fps (N)
Video Bit Rate: 32 Kbps-6 Mbps
Audio Output: 1-ch, RCA (Linear, 1 K?)
Audio Bit Rate: 64 Kbps
Dual-Stream: Support
Stream Type: Video, Video & Audio
Synchronous Playback: 8-ch
Playback Resolution: 720P/VGA/WD1/4CIF/CIF
Network Interface: 1; 10M / 100M self-adaptive Ethernet interface
Network Protocol: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
Network Incoming Bandwidth: 32 Mbps
Remote Connections: 128
USB Interface: 2 × USB 2.0
Capacity: Up to 6 TB capacity for each disk
SATA: 1 SATA interface
eSATA: 1 eSATA interface
Power Supply: 12 VDC
Consumption: ? 20 W
Working Temperature: -10 °C to +55 °C (14 °F to 131 °F)
Working Humidity: 10% to 90%
Chassis: 1U chassis
Dimensions: 260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch)
Weight: ? 1.2 kg (2.6 lb)
Installation: Desktop installation
Warranty: 2-year warranty
Mobile Monitoring: Hik-Connect or iVMS-4500
